TCP/IP-Based Control and Monitoring of Manufacturing System

Abstract:

In this paper, a framework for remote monitoring and controlling of manufacturing system at lower level of automation in manufacturing is proposed. This framework has capability to develop the higher level of automation in manufacturing. In order to proof that the proposed framework can be implemented, a demo system based on the framework is built.Computer-Integrated Manufacturing (CIM) system as a manufacturing system is controlled and monitored remotely within demo system was utilised. In general, the system consists of two Graphical User Interface (GUI) program; one as a client and the other one as server program connected using TCP/IP protocol. The system proposed include the CIM system which connected to the server computer and able to controlled and monitored via the client GUI program. In addition for demonstration purposes, several sub-systems of the CIM system which includes the conveyor, stoppers, sensors and the pick and place robot were used to control and monitor the system development. The programming language used in this system is Visual C++ with Microsoft Foundation Class (MFC) application. The overall developed system has successfully demonstrates the ability of remotely control the system.

• Periodical: Advanced Materials Research (Volume 845)
• Pages: 975-979
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.845.975
• Online since: December 2013
• Authors: M. Abrishamkar, Mohamed Hussein, K. Zakaria*, H. Maleki
• Keywords: CIM, Monitoring, Remote Control, TCP/IP

References

[1] Wang, Y.M., et al., Internet-based remote manipulation and monitoring of an industry robot in advanced manufacturing systems. The International Journal of Advanced Manufacturing Technology, 2009. 43 (9): pp.907-913.

DOI: 10.1007/s00170-008-1768-y

[2] Yi-Hong Long, Zu-De Zhou, Quan Liu, Ben-Yuan Chen, Heng-LinZhou, Embedded-based modular NC systems, The International Journal of Advanced Manufacturing Technology , volume: 40, Feb. 2009, p.7–8, DOI: 10. 1007/s00170-008-1384-x.

[3] Wen-Zheng, Z. and H. Yue-li. Design and Implementation of CNC Machine Remote Monitoring and Controlling System Based on Embedded Internet. in Intelligent System Design and Engineering Application (ISDEA), 2010 International Conference on. 2010. IEEE.

DOI: 10.1109/isdea.2010.283

[4] Wang, G., et al., Research and exploitation of CNC laser manufacturing online monitoring system based on OpenGL. 2010: pp. 79973A-79973A.

[5] Lan, H., Web-based rapid prototyping and manufacturing systems: A review. Computers In Industry, 2009. 60 (9): pp.643-656.

DOI: 10.1016/j.compind.2009.05.003

[6] M. P. Groover, Automation, Production Systems and Computer Integrated Manufacturing, 3rd edition: Pearson Education, Inc., Upper Saddle River, New Jersey, (2008).
