Silicon-Based Multichannel Probe Integrated with a Front End Low Power Neural Recording IC for Acute Neural Recording

Abstract:

This work presents a silicon-based multichannel probe integrated with a front end low power neural recording integrated circuit (IC) which is used in acute neural recording application. The low power neural recording IC contains 100-channel analog recording front-ends, 10 multiplexing successive approximation register ADCs, digital control modules and power management circuits. The 100-channel neural recording IC consumes 1.16-mW, making it the optimum solution for multi-channel neural recording systems. The neural recording IC and Si probe are integrated in a printed circuit board (PCB) which is fixed on the skull using dental resin. Digital neural signal is converted to analog signal and output by neural recording IC. The signal-to-noise ratio of neural recording signal can be increased through the reduction of interconnect length. The buckling strength of the fabricated probes was simulated using finite element analysis and measured by compression tester. The packaging method of 2D probe and neural recording IC was successfully demonstrated. The impedance of the assembled probe is also measured and discussed. To verify the functionality of Si probe integrated with neural recording IC, a pseudo neural signal acquisitions have been perform.

• Periodical: Advanced Materials Research (Volume 849)
• Pages: 189-194
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.849.189
• Online since: November 2013
• Authors: Ming Yuan Cheng*, Kwan Ling Tan, Wei Guo Chen, Rui Qi Lim, Maria Ramona B. Damalerio, Lei Yao, Peng Li, Yuan Dong Gu, Min Kyu Je
• Keywords: IC, Implant, Low Power, Neural Probe, Si

References

[1] M. Velliste, S. Perel, M. C. Spalding, A. S. Whitford, and A. B. Schwartz, Cortical control of a prosthetic arm for self-feeding, Nature, vol. 453, (2008), pp.1098-1101.

DOI: 10.1038/nature06996

[2] L. R. Hochberg, M. D. Serruya, G. M. Friehs, J. A. Mukand, M. Saleh, A. H. Caplan, A. Branner, D. Chen, R. D. Penn, and J. P. Donoghue, Neuronal ensemble control of prosthetic devices by a human with tetraplegia, Nature, vol. 442, (2006).

DOI: 10.1038/nature04970

[3] S. Kim, R. Bhandari, M. Klein, S. Negi, L. Rieth, P. Tathireddy, M. Toepper, H. Oppermann, and F. Solzbacher, Integrated wireless neural interface based on the Utah electrode array, Biomedical Microdevices, vol. 11, (2009), pp.453-466.

DOI: 10.1007/s10544-008-9251-y

[4] S. M. E. Merriam, O. Srivannavit, M. N. Gulari, and K. D. Wise, A Three-Dimensional 64-Site Folded Electrode Array Using Planar Fabrication, Journal of Microelectromechanical Systems, vol. 20, (2011), pp.594-600.

DOI: 10.1109/jmems.2011.2127450

[5] A. A. A. Aarts, O. Srivannavit, K. D. Wise, E. Yoon, R. Puers, C. Van Hoof, and H. P. Neves, Fabrication technique of a compressible biocompatible interconnect using a thin film transfer process, Journal of Micromechanics and Microengineering, (2011).

DOI: 10.1088/0960-1317/21/7/074012

[6] Website of NeuroNexus probe, http: /www. neuronexus. com.

[7] Website of Floating Microelectrode Arrays, http: /www. microprobes. com/index. php/products/multi-channel-arrays/fma-floating-microelectrode-arrays.

[8] X. Zou, L. Liu, J. H. Cheong, L. Yao, P. Li, M. Y. Cheng, W. L. Goh, R. Rajkumar, G. S. Dawe, K. W. Cheng, and M. Je, A 100-Channel 1-mW Implantable Neural Recording IC,, IEEE Transactions on Circuits and Systems I, (2013), pp.1-13.

DOI: 10.1109/tcsi.2013.2249175

[9] W. Jensen, U. G. Hofmann and K. Yoshida, Assessment of subdural insertion force of single tine microelectrodes in rat cerebral cortex, 25th Annual International Conference of the IEEE EMBS, (2003), p.2168–2171.

DOI: 10.1109/iembs.2003.1280170
