The Impact of λ/4 Type Absorber Protective Layer 's Thickness on Absorbing Properties

Abstract:

Abstract .Electromagnetic radiation affects normal operation of electronic devices and causes harm to human health, the use of electromagnetic radiation protective material, especially the electromagnetic wave absorption material, is an effective method for interference control and radiation protection, λ / 4 type dielectric absorber with a simple and practical nature, the protective layer should be added to ensure its durability in practice, this article discusses the gypsum board as the substrate, the thickness of conventional protective layer's material impacts on the absorbing properties. Studies show that: the position of absorption peak moves to lower frequency with increase of the protective layer's thickness by the theory and experiment, this paper puts forward the protective layer's thickness criterion's impact on the absorption characteristics, the thickness less than 0.05 cm has little effect on absorption characteristics in S band , which can simplify theoretical calculation and be convenient to select a material; when the thickness of the protective layer has a significant effect on absorption, the relationship among the parameters of absorber can be found according to theoretical simulation, thereby reducing or eliminating the impact of protective layer thickness on absorption characteristics.

• Periodical: Advanced Materials Research (Volumes 881-883)
• Pages: 1245-1249
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.881-883.1245
• Online since: January 2014
• Authors: Hui Chao Zhao, Wan Jun Hao*, Ying Ying Yi, Yi Feng Dong, Fan Wu, Ming Ming Wang, Dong Wei Chen
• Keywords: Absorption Characteristics, Protective Layer Thickness, λ 4 Type Absorber

References

[1] SM. Xue, WLAN and implementation technique Journal of Northwest University for Nationalities(Natural Science), Vol. 24 No. 3（2003） P: 50-56.

[2] O. Hashimoto《Technologies and Applications of Wave Absorber》ＣＭＣ, 2004. P：10-30.

[3] W.J. Hao, Measure and countermeasures. of Electromagnetic radiation . Miyagi prefecture ITC research report 2001 , 3 : P3-10.

[4] S.H. Liu, J.M. Liu and X.L. Dong. electromagnetic wave shielding and absorbing material , ，chemical industry press, Beijing. 2007. P: 50-80.

[5] Adam J. Douglas, Davis Lionel E, etc, Ferrite device and materials, IEEE Trans. on Microwave Theory and Technology . Vol. 50. No. 3(2002), P: 721-724.

[6] S.H. Wang, F. Wen and W.J. Hao. 2006. Electromagnetism Pollution and Protection Materials for Electromagnetic Radiation, Environmental Science and Technology, 12(29): P: 96-98.

[7] Lv Shuzhen, vestbo, sigfusson, HuoJiChuan. Interference in transmission line theory and its application in cement-based materials [J]. Journal of changchun university of science and technology (natural science edition), 2010 (02).

[8] J.J. Chen W.J. Hao* Y.F. Zhang X.L. Zhao Stretching Design For Plasterboard Of λ/4 Type EMW-Absorber International Conference on Heterogeneous Material Mechanics (ICHMM), JUN 03-08, P：533-536.

[9] Y. nayitou，《 E M Wave Absorber》，Omu press in Japan ，１９８７，Tokyo P: 20-40.

[10] O. Hashimoto，《Introduction to Wave Absorber》，Morikita press in Japan，1997, P10—30.
