Influence of Short Thermal Cracks on the Material Behaviour of a Railway Wheel Subjected to Repeated Rolling

Abstract:

An analysis of whether and how the occurrence of shallow (radial) thermal cracks promotes additional plastic deformation of a mechanically loaded wheel tread is carried out. The study employs numerical simulations of a 2D slice of an elastoplastic railway wheel tread containing thermal (radial) cracks. The cracked wheel material is subjected to repeated passes of a frictional rolling contact load. The effect of the existing thermal cracks on bulk deformation and subsequent rolling contact promoted growth is quantified. Results indicate that thermal cracks of a depth of 0.1 mm have a negligible effect, whereas 1.0 mm cracks significantly decrease the bulk resistance of the wheel material. Further, it is shown how the magnitude of stress, strain and deformation depends on the direction of applied traction.

• Periodical: Advanced Materials Research (Volumes 891-892)
• Pages: 1139-1145
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.891-892.1139
• Online since: March 2014
• Authors: Sara Caprioli*, Anders Ekberg
• Keywords: Rolling Contact Fatigue (RCF), Thermal Cracking

References

[1] S. Caprioli, T. Vernersson, and A. Ekberg. Thermal Cracking of a RailwayWheel Tread due to Tread Braking-Critical Crack Sizes and Influence of Repeated Thermal Cycles,. In: Proc IMech Part F: J Rail and Rapid Transit 227. 1 (2011), pp.10-18.

DOI: 10.1177/0954409712452347

[2] M. C. Dubourg and B Villechaise. Analysis of Multiple Fatigue Cracks - Part I : The- ory,. In: Journal of Tribology 114. July (1992), p.455, 461.

DOI: 10.1115/1.2920905

[3] M. C. Dubourg,M. Godet, and B. Villechaise. Analysis ofMultiple Fatigue Cracks-Part II: Results,. In: Journal of Tribology 114 (1992), p.462, 468.

DOI: 10.1115/1.2920906

[4] J.W. Ringsberg andA. Bergkvist. On propagation of short rolling contact fatigue cracks,. In: Fatigue Fracture of EngineeringMaterials and Structures 26. January (2003), pp.969-983.

DOI: 10.1046/j.1460-2695.2003.00657.x

[5] T. Vernersson, S. Caprioli, E. Kabo, H. Hansson, and A. Ekberg. Wheel tread dam- age: a numerical study of railway wheel tread plasticity under thermomechanical load- ing,. In: Proceedings of the Institution of Mechanical Engineers, Part F: Journal of Rail and Rapid Transit 224. 5 (Sept. 2010), pp.435-443.

DOI: 10.1243/09544097jrrt358

[6] R. Lewis and U. Olofsson, eds. Wheel-rail interface handbook. Oxford, Cambridge, New Delhi: Woodhead Publishing Limited and CRC Press LLC, 2009. ISBN: 978-1-84569- 412-8.

[7] Abaqus. Abaqus Analysis User's Manual. 6. 10. Providence, Rhode Island USA: Simulia, (2010).

[8] H. Hertz. Ueber die Beruehrung fester elastischer Körper (On the contact of elastic solids),. In: J. reine und angewandte Methematik 92 (1882), pp.156-171.

DOI: 10.1515/9783112342404-004

[9] J. Lemaitre and J. L. Chaboche. Mechanics of Solid Materials. Cambridge UK: Cam- bridge University Press, 1990. ISBN: 9780521477581. DOI: 10. 2277/0521477581.

[10] H. Hansson. Thermo-mechanical simulation of block braked wheel. Gothenburg, Sweden: Chalmers University of Technology, Division of Solid Mechanics, (2008).
