Fatigue and Fatigue Crack Propagation of Laser Beam-Welded AA2198 Joints and Integral Structures

Abstract:

To meet the future demands of the aerospace industry with respect to safety, productivity, weight, and cost, new materials and joining concepts have being developed. Recent developments in the metallurgical field now make it possible to use laser-weldable Al-alloys of the 2xxx series such as AA2198 with a high structural efficiency index due to their high strength and low density. AA2198 holds the promise of providing a breakthrough response to the challenges of lightweight design in aircraft applications. Laser beam welding as an efficient joining technology for fuselage structures is already established in the aircraft industry for lower fuselage panels because the welded panels provide a higher buckling strength and lower weight compared with the classical riveted designs. The key factor for the application of laser-welded AA2198 structures is the availability of reliable data for the assessment of their damage tolerance behavior. In the research presented, the mechanical properties with regard to fatigue and fatigue crack propagation of laser beamwelded AA2198 joints and four-stringer panels were investigated. It was found that the fatigue endurance limit of laser beamwelded AA2198T3 is approximately 25 % below the endurance limit of the base material. With regard to the fatigue crack propagation behavior, the laser beam welded four-stringer panels with T-joints show a fatigue life increased by a factor of 1.7 compared with the base material. This work shows that high-quality laser beam welds of AA2198 can be produced on a large scale using the laser beam welding facilities of the Helmholtz-Zentrum Geesthacht.

• Periodical: Advanced Materials Research (Volumes 891-892)
• Pages: 1457-1462
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.891-892.1457
• Online since: March 2014
• Authors: Nikolai Kashaev*, Sergey Chupakhin, Josephin Enz, Volker Ventzke, Anne Groth, Manfred Horstmann, Stefan Riekehr
• Keywords: AA2198, Al-Li Alloys, Fatigue, Fatigue Crack Propagation, Laser Beam Welding

References

[1] D. Dittrich, J. Standfuss, J. Liebscher, B. Brenner, E. Beyer, Physics Procedia, 12 (2011) 113–122.

DOI: 10.1016/j.phpro.2011.03.015

[2] B. Lenczowski, in: Proceedings of the 23rd Congress of International Council of the Aeronautical Sciences, Toronto, Canada, 2002, p.4101. 1-4101. 4, http: /www. icas. org.

[3] P.E. Magnusen, P.E. Mooy, L.A. Yocum, R.J. Rioja, in: Proceedings of the 13th International Conference on Aluminium Alloys (ICAA-13), 2012, http: /www. tms. org.

[4] Ch. Glazebrook, J. Laye, S. Kempa, Laser Beam Welding of AIRWARE, Sixth International TWI/EWI Aerospace Seminar on Joining of Aerospace Materials, Munich, Germany 13th – 14th Sept. (2012).

[5] Laser beam welding of newly developed Al-Li alloy (LAWENDEL), EU FP7 Project, information on http: /www. hzg. de/public_relations/press_releases/036670/index_0036670. html. en.

[6] M. Pacchione, J. Telgkamp, in: Proceedings of the 25th International Congress of the Aeronautical Sciences (ICAS), Hamburg, Germany, 2006, pp.1-12, http: /www. icas. org.

[7] Cost effective Integral metallic Structure (COINS). 3rd/Final Periodic Activity Report. SIXTH FRAMEWORK PROGRAMME, PRIORITY 4, Aeronautics and Space, Specifically Targeted Research Project, 2010, information on http: /cordis. europa. eu.

[8] P. Irving, Yu.E. Ma, X. Zhang, G. Servetti, S. Williams, G. Moore, J. dos Santos, M. Pacchione, in Proceedings of the 25th ICAF Symposium of the International Committee on Aeronautical Fatigue, Rotterdam, 2009, pp.387-405.

DOI: 10.1007/978-90-481-2746-7_23

[9] Yu.E. Ma, P. Irving, Journal of Aircraft, 48, n. 4 (2011) 1238-1244.

[10] Yu.E. Ma, B.Q. Liu, Zh.Q. Zhao, Applied Mechanics and Materials, 138-139 (2011) 651-656.

[11] P. Cavaliere, A. de Santis, Metallurgical Science and Technology, 26-2 (2008) 21-30.

[12] J. Enz, S. Riekehr, V. Ventzke, N. Kashaev, N. Huber, Welding and Cutting, 64, n. 8 (2012) 482-485.

[13] J. Enz, S. Riekehr, V. Ventzke, N. Kashaev, Physics Procedia, 39 (2012) 51-58.

DOI: 10.1016/j.phpro.2012.10.013

[14] S. Chupakhin. Laser beam welding process development for AA2198 and AA2139 butt joints. Master Thesis, Helmholtz-Zentrum Geesthacht, Geesthacht, (2013).

DOI: 10.22449/1573-160x-2020-6-631-658

[15] N. Kashaev, J. Enz, M. Horstmann, A. Groth, V. Ventzke, S. Riekehr, N. Huber. Quality assessment of laser beam welded AA2198 integral structures, in: Proceedings of the 27th Symposium of the International Committee on Aeronautical Fatigue, ICAF 2013, vol. 2 Jerusalem (IL), 03. -07. 06. 2013, 2013, pp.737-749.

DOI: 10.4028/www.scientific.net/amr.891-892.1457

[16] ASTM Standard E647, Standard test method for measurement of fatigue crack growth rates, ASTM International, West Conshohocken, 2008, doi: 10. 1520/E0647-08.

DOI: 10.1520/stp33449s

[17] W.V. Vaidya, P. Staron and M. Horstmann, Fatigue Fract. Engng. Mater. Struct., 35 (2011) 399-411.
