High-Performance Multilevel-Storage Cu-Doped SiO_x-Based Nonvolatile Resistance Memory Using Ion Bombardment Technique

Abstract:

Multi-level-cell (MLC) operation of Cu-doped SiO_x-based (SiO_x:Cu-based) resistance random access memory (ReRAM) has been reported for the first time. For this study, we employed a novel ion bombardment-induced (IB-induced) SiO_x:Cu switching layer (SL). Using modulation of SET-current compliance, we completed 2-bit-per-cell memory application. The MLC resistance switching process is described in detail. Owing to controllability of Cu source from advanced IB technique, the IB-induced SiO_x:Cu SL shows good cell-to-cell uniformity of MLC resistance switching parameters, including operation voltages and resistance states. Additionally, the IB-induced TaN/SiO_x:Cu/TaN ReRAM exhibits infinite potential for MLC operation, such as over 3 times differentiation space among memory states, robust resistance retention, and promising operation endurance properties. During frequent MLC resistance switching, moreover, the IB-induced SiO_x:Cu-based device also has excellent single-cell uniformity of memory states due to IB-induced thin Cu filament.

You might also be interested in these eBooks

Advanced Materials and Engineering Materials III

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 893)

Pages:

794-797

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.893.794

Citation:

Cite this paper

Online since:

February 2014

Authors:

Wen Luh Yang*, Chin Hsuan Liao, Sheng Hsien Liu

Keywords:

Cu-Doped SiO_x, Ion Bombardment (IB), Multi-Level-Cell (MLC), ReRAM

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] S. Yu et al., Compact modeling of conducting-bridge random-access memory (CBRAM), IEEE Trans. Electron Devices 58 (2011) 1352-1360.

DOI: 10.1109/ted.2011.2116120

Google Scholar

[2] S. -H. Liu et al., A novel ion-bombarded and plasma-passivated charge storage layer for SONOS-type nonvolatile memory, IEEE Electron Device Lett. 33 (2012) 1393-1395.

DOI: 10.1109/led.2012.2207699

Google Scholar

[3] L. Zhang et al., Unipolar resistive switch based on silicon monoxide realized by CMOS technology, IEEE Electron Device Lett. 30 (2009) 870-872.

DOI: 10.1109/led.2009.2024650

Google Scholar

[4] S. Jou et al., Influence of interfacial tantalum oxynitride on resistive switching of Cu/Cu -SiO2/TaN, Jpn. J. Appl. Phys. 51 (2012) 055701.

DOI: 10.7567/jjap.51.055701

Google Scholar

[5] S. -H. Liu et al., Novel ion bombardment technique for doping limited Cu source in SiOx-based nonvolatile switching layer, IEEE Electron Device Lett. 34 (2013) 1388-1390.

DOI: 10.1109/led.2013.2280286

Google Scholar
