Detection and Application of Hull Weld Quality Based on MATLAB Image Processing

Abstract:

Proposed on the basis of nondestructive testing technology, such as ultrasonic testing and X-ray detecting, image processing of hull welding based on MATLAB is a simple detecting method to detect the quality of welding. By image processing, physical dimensions, such as circumferences and shapes, as well as the intensity and texture features of welds can be concluded. Then, through numerical analysis, quality problems, including porosities, slags, undercuts, overlaps, welding defects and others, if exist, can be determined. This method decreases the cost and reduces the harm to people’s health. Experimental results showed that the detecting system can calculate and determine the major features of the welds effectively and accurately, and possesses good practical value.

• Periodical: Advanced Materials Research (Volumes 912-914)
• Pages: 1509-1512
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.912-914.1509
• Online since: April 2014
• Authors: Kai Jun Chen*
• Keywords: Hull Weld, Image Processing, Nondestructive Testing

References

[1] Xu xiaoming, Zhang hua. The image identification method for the welding line's initial position in local environment[J]. welding technique, 2011（11）： 10-11.

[2] Zhou zhiyong. The research of image automatic identification method for the defect of hull weld's X-ray. Master Thesis. Shang hai, (2007).
