HomeAdvanced Materials ResearchAdvanced Materials Research Vols. 912-914Influence of Heat Treatment Parameters on...

Influence of Heat Treatment Parameters on Mechanical Properties and Crashworthiness of Aluminum Crash Box

Abstract:

The influence of heat treatment parameters, i.e. solution temperature, solution time, aging temperature and aging treatment on the mechanical properties and crashworthiness of crash boxes produced with 6101 aluminum alloy were studied. The optimal heat treatment processing was obtained as follows: 510°C×45min+175°C×7h. The crash boxes were treated under different heat treatments, i.e. T1 temper,T4 temper and T6 temper and then compressed under static pressure. The results indicate that the energy absorption of crash box can after T6 treatment is significantly higher than the samples under T1temper and T4 temper, which have similar energy absorption. The peak force of static pressure crash boxes treated under T6 temper is obviously higher than the other two tempers.

You might also be interested in these eBooks

Frontiers of Advanced Materials and Engineering Technology II

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 912-914)

Pages:

194-199

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.912-914.194

Citation:

Cite this paper

Online since:

April 2014

Authors:

Jia Zhou*, Guang Yao Wang, Yang Li, Xin Ming Wan

Keywords:

Aluminium Alloy, Energy Absorbing Capacity, Heat Treatment, Mechanical Property

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Aluminium Automotive Manual. Internet address: www. eaa. net/aam.

Google Scholar

[2] The Aluminium Association. Aluminium Standards and Data. The Aluminium Association, Inc., Washingtong, DC, (1997).

Google Scholar

[3] The Aluminium Association. Automotive Aluminium Crash Energy Management Manual AT5[M]. The Aluminium Association, Inc., Washingtong, DC, (1998).

Google Scholar

[4] A. Rogers, M. Jarrett, Aluminium Extrusions for Automotive Applications, Materials World, Vol. 6(1998), p.18.

Google Scholar

[5] Jing Bi, Hongbing Fang, Qian Wang. Modeling and optimization of foam-filled thin-walled columns for crashworthiness designs. Finite Element in Analysis and Design, Vol. 46(2010), p.698.

DOI: 10.1016/j.finel.2010.03.008

Google Scholar

[6] J. Zhou, X. M. Wan, Y. Li, Q. J. Zhao. Optimal design and experimental investigations of aluminium extrusion profiles for lightweight of car bumper. Key Engineering Materials Vol. 585 (2014), p.157.

DOI: 10.4028/www.scientific.net/kem.585.157

Google Scholar
