A Phase-Field Model for the Formation of Martensite and Bainite

Abstract:

The phase field method is rapidly becoming the method of choice for simulating the evolution of solid state phase transformations in materials science. Within this area there are transformations primarily concerned with diffusion and those that have a displacive nature. There has been extensive work focussed upon applying the phase field method to diffusive transformations leaving much desired for models that can incorporate displacive transformations. Using the current model, the formation of martensite, which is formed via a displacive transformation, is simulated. The existence of a transformation matrix in the free energy expression along with cubic symmetry operations enables the reproduction of the 24 grain variants of martensite. Furthermore, upon consideration of the chemical free energy term, the model is able to utilise both the displacive and diffusive aspects of bainite formation, reproducing the autocatalytic nucleation process for multiple sheaves using a single phase field variable. Transformation matrices are available for many steels, one of which is used within the model.

• Periodical: Advanced Materials Research (Volume 922)
• Pages: 31-36
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.922.31
• Online since: May 2014
• Authors: Tansel T. Arif*, Rong Shan Qin
• Keywords: Bainite, Displacive, Martensite, Phase Field

References

[1] L. Chen, A. Khachaturyan, Computer simulation of structural transformations during precipitation of an ordered intermetallic phase, Acta metallurgica et materialia 39(1991) 2533–2551.

DOI: 10.1016/0956-7151(91)90069-d

[2] Y. Wang, L.-Q. Chen, A.G. Khachaturyan, Kinetics of strain-induced morphological transformation in cubic alloys with a miscibility gap, Acta Metallurgica et Materialia 41(1993) 279–296.

DOI: 10.1016/0956-7151(93)90359-z

[3] J. Langer, Models of pattern formation in first-order phase transitions, in: G. Grinstein and G. Mazenko (Eds.) Directions in Condensed Matter Physics, World scientific, Singapore, 1986, p.165–185.

DOI: 10.1142/9789814415309_0005

[4] W.J. Boettinger, J.A. Warren, C. Beckermann, A. Karma, Phase-Field Simulation of Solidification 1, Annual Review of Materials Research 32(2002) 163–194.

DOI: 10.1146/annurev.matsci.32.101901.155803

[5] L. Chen and W. Yang, Computer simulation of the domain dynamics of a quenched system with a large number of nonconserved order parameters: The grain-growth kinetics, Physical Review B 50(1994).

DOI: 10.1103/physrevb.50.15752

[6] Steinbach, F. Pezzolla, B. Nestler, A phase field concept for multiphase systems, Physica D: Nonlinear …, 94(1996) 135–147.

DOI: 10.1016/0167-2789(95)00298-7

[7] Kazaryan, Y. Wang, B. Patton, Generalized phase field approach for computer simulation of sintering: Incorporation of rigi-body motion, Scripta Mater. 41(1999) 487–492.

DOI: 10.1016/s1359-6462(99)00179-7

[8] Wheeler, W. Boettinger, G. McFadden, Phase-field model for isothermal phase transitions in binary alloys, Physical Review A 45(1992) 7424–7440.

DOI: 10.1103/physreva.45.7424

[9] H. K. D. H. Bhadeshia, Worked examples in the Geometry of Crystals Second edition, London, (1987)

[10] T.T. Arif, R.S. Qin, A phase-field model for bainitic transformation, Computational Materials Science 77(2013) 230–235.

DOI: 10.1016/j.commatsci.2013.04.044

[11] H. K. D. H. Bhadeshia, Bainite in steels Second edition, London, 1992.

[12] J. W. Cahn, J. E. Hilliard, Free energy of a nonuniform system. I. Interfacial free energy, J. Chem. Phys. 28(1958) 258–266.

DOI: 10.1063/1.1744102

[13] Sundman, J. Ågren, A regular solution model for phases with several components and sublattices, suitable for computer applications, Journal of physics and chemistry of solids 42(1981) 297-301.

DOI: 10.1016/0022-3697(81)90144-x
