A Study Comparative of Cu and Cu-Zn Electrode during Electrical Discharge Machining on Martensitic Stainless Steel AISI 410

Abstract:

The objective of this research is to study comparisons of Cu and CuZn electrodes, during Electrical Discharge Machining (EDM) of martensitic stainless AISI 410. The workpiece material was a rectangular plate, measuring 30x50x5 mm. The conditions of the EDM process were 3.0mm depth and 2.0 mm diameter, with variables of parameter being: currents, on/off-times and open circuit voltages of spark. Evaluation of the electrical discharge was conducted using Material Removal Rate (MRR), Electrode Wear Ratios (EWR) and Arithmetical Mean Roughness (Ra), respectively. The results found that CuZn electrode materials provide higher MRR and EWR than electrode materials of Cu. Also, when considering the melting of white layer, initial melts found that the white layer surface material is also good for the integrity of the state park, and it was additionally also found that when the current level increases, then that will rise accordingly.

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 327-332
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.327
• Online since: May 2014
• Authors: Rattikorn Saodaen*, Janmanee Pichai, Somchai Wonthaisong, Apiwat Muttamara
• Keywords: AISI 410, Cu, Cu-Zn, EDM, Electrode

References

[1] Kalpakjian S, Schmid SR, 2001 Manufacturing engineering and technology, 4th edn. Prentice Hall, Upper Saddle River.

[2] W. Koenig, D.F. Dauw, G. Levy, U. Panten, EDM future steps towards the machining of ceramics, Ann. CIRP 37 (2) (1998) 625–631.

DOI: 10.1016/s0007-8506(07)60759-8

[3] F. Ghanema et al, 2003. et al, Influence of steel type on electrical discharge machined surface integrity. Journal of Materials Processing Technology: Vol. 142, p.163–173.

DOI: 10.1016/s0924-0136(03)00572-7

[4] P. Snrinivasaroa et al, 2010. Parametric Study of Electrical Discharge Machining of AISI 304 Stainless steel. International Journal of Engineering Science and Technology: Vol. 2(8), pp.3535-3550.

[5] A.A. Khan, 2007. Electrode wear and material removal rate during EDM of aluminum and mild steel using copper and brass electrode. The International Journal of Advanced Manufacturing. Vol. 39, pp.482-487.

DOI: 10.1007/s00170-007-1241-3

[6] G. Vasudevamurthy T.W. Knight. 2007. Effect of system parameters on size distribution of 304 stainless steel particles produced by electrical discharge mechanism. Materials Letters Volume 61, Issue 27, November 2007, p.4872–4874.

DOI: 10.1016/j.matlet.2007.03.070

[7] A. Muttamara. A comparative study using copper brass graphite electrode types during, Electrical Discharge Machining. Science and Technology Journals, Thammasat University. Vol. 17. No 2, (2009) pp.43-49.

[8] P. Janmanee . et al, Investigation of Electrical Discharge Machining of Tungsten Carbide using EDM-C3 Electrode Material. European Journal of Scientific Research. Vol. 76. No. 1 (2012), pp.133-142.

[9] Singh, S et al, 2004. Some Investigation into the Electric Discharge Machining of Hardened Tool Steel Using Different Electrode Materials. Journal of Materials Processing Technology Vol. 149 (1-3), pp.272-277.

DOI: 10.1016/j.jmatprotec.2003.11.046

[10] P. Janmanee and A. Muttamara. Optimization of Electrical Discharge Machining of Composite 90WC-10Co Base on Taguchi Approach. European Journal of Scientific Research Vol. 64 No. 3 (2011), pp.426-436.

[11] Bu¨lent Ekmekci : Residual stresses and white layer in electric discharge machining (EDM)., Applied Surface Science 253 (2007) 9234-9240.

DOI: 10.1016/j.apsusc.2007.05.078
