Layer Formation of SAPO-34 Zeotype Material by EPD Seeding Method Followed by Hydrothermal Secondary Growth

Abstract:

Fine layer growth of SAPO-34 crystals on the steel and α-alumina substrates has been investigated by electrophoretic deposition (EPD) followed by secondary growth. At first step, two sizes of SAPO-34 seeds with different composition of precursor solution were synthesized. Thereafter the best quality of the seeds in term of crystal size was selected for seeding operation. All seeded samples were prepared by electrophoretic deposition (EPD) with 0.4 wt% powder in solution, voltage of 4.5 V and deposition time of 90 min, followed by the secondary growth in a Teflon lined autoclave for crystallization at 473K for 24 hr. The prepared fine seeds characterized by XRD and SEM analysis. Also the substrates were broken and characterized by SEM methods in terms of surface coverage and mean size of the particles. The results revealed a better quality of the coated film on the surface of steel rather than α-alumina on the base of homogeneity and crystal size.

You might also be interested in these eBooks

Materials Science and Engineering Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 936)

Pages:

259-263

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.936.259

Citation:

Cite this paper

Online since:

June 2014

Authors:

S.M. Hosseini Davarani*, Sh. Fatemi, Z. Jabbari

Keywords:

Electrophoretic Deposition (EPD), Fine Layer Formation, Hydrothermal Crystallization, SAPO-34 Zeotype

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. Caro, M. Noack, Zeolite membranes – Recent developments and progress, Microporous and Mesoporous Materials 115 (2008) 215–233.

DOI: 10.1016/j.micromeso.2008.03.008

Google Scholar

[2] Y. Hirota, K. Watanabea, Y. Uchida, Y. Egashira, K. Yoshida, Y. Sasaki, N. Nishiyama, Coke deposition in the SAPO-34 membranes for examining the effects of zeolitic and non-zeolitic pathways on the permeation and separation properties in gas and vapor permeations, Journal of Membrane Science 415–416 (2012).

DOI: 10.1016/j.memsci.2012.04.050

Google Scholar

[3] S. Li, J. L. Falconer, R. D. Noble, SAPO-34 membranes for CO2/CH4 separation, Journal of Membrane Science 241 (2004) 121–135.

DOI: 10.1016/j.memsci.2004.04.027

Google Scholar

[4] J. Hedlund, J. Sterte, M. Anthonis, A. Bons, B. Carstensen, N. Corcoran, D. Cox, H. Deckman, W. D. Gijnst, P. de Moor, F. Lai, J. McHenry, W. Mortier, J. Reinoso, J. Peters, High-flux MFI membranes, Microporous and Mesoporous Materials 52 (2002).

DOI: 10.1016/s1387-1811(02)00316-5

Google Scholar

[5] J. K. Das, N. Das, S. N. Roy, S. Bandyopadhyay, The growth of SAPO 34 membrane layer on support surface for gas permeation application, Ceramics International 38 (2012) 333–340.

DOI: 10.1016/j.ceramint.2011.07.011

Google Scholar

[6] T. L. Chew, A. L. Ahmad, S Bhatia , Rapid synthesis of thin SAPO-34 membranes using microwave heating, Journal of Porous Materials 18 (2011) 355–360.

DOI: 10.1007/s10934-010-9385-1

Google Scholar

[7] Z. Jabbari, Sh. Fatemi, M. Davoodpour, Comparative study of seeding methods; dip-coating, rubbing and EPD, in SAPO-34 thin film fabrication, Advanced Powder Technology, 2013(article in press).

DOI: 10.1016/j.apt.2013.05.011

Google Scholar

[8] T. Seike, M. Matsuda, M. Miyake, Fabrication of Y-type zeolite films by electrophoretic deposition, Solid State Ionics 151 (2002) 123–127.

DOI: 10.1016/s0167-2738(02)00590-8

Google Scholar
