User Interface Design of 1090ES Mode Embedded Ground-Based Transceiver System

Abstract:

The novel user interface design of 1090ES Mode embedded ground-based transceiver (GBT) system is introduced in this paper. 1090ES mode is applied to the GBT system to receive airborne Automatic Dependent Surveillance-Broadcast (ADS-B) data. The output data of the GBT system are obtained through system’s serial port by processing information of ADS-B segment in 1090ES information structure. The novel user interface is based on Linux operating system and cross-complied on ARM platform to realize flight display function. The 1090ES mode data sent from aircraft is accurately recognized by ADS-B system software based on Linux, and precisely located in graphical interface either. The improved ADS-B system software in this user interface design occupies less resource, and can be easily transplanted to other embedded platform through cross-complied embedded Quasar Technologies (Qt) software. The complicated receiving and display of GBT system can be transformed into small size and portable device (4.6 inches) through this user interface design.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1733-1738
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1733
• Online since: June 2014
• Authors: De Yin Zhang, Xiao Yu, Zhi Yong Liu
• Keywords: 1090ES Mode, ADS-B, Embedded System, GBT, Interface Design

References

[1] De-Yin Zhang, Xiao Yu, Zhi-Yong Liu, et al. Investigation Of ADS-B Information Transmission And Its Anti-interference Technology[C][in Chinese]. Universal Aviation of China, 2013, pp.153-157.

[2] FAA. Ground Based-Transceiver (GBT) For Broadcast Services Using the Universal Access Transceiver (UAT) Data Link[S]. 2003. pp.1-5.

[3] Cheng-Lan Zhang, et al. Design and realization of reconfigurable communication in human-machine interface based on Linux[J] [in Chinese]. Computer Engineering and Applications, 2011, 47(7): 61-63.

[4] Zhi-Qiang Zhang. Planning and Construction of ADS-B Ground Station[J] [in Chinese]. Command Information System and Technology, 2011, 2(4): 27-30.

[5] ICAO. Comparative Analysis of ADS-B Data Links[R]. AN-Conf /11-IP/12. Montreal, CANADA, (2003).

[6] Yi-Jiang Zhen, The Performance Analysis of Mode S System Based On ADS-B[J] [in Chinese]. Journal of China Academy of Electronic and Information Technology. 2011, 6(4). 391-394.

[7] RTCA. Minimum Operational Performance Standards for 1090 MHz Extended Squitter Automatic Dependent Surveillance – Broadcast (ADS-B) and Traffic Information Services – Broadcast (TIS-B)[S]. 2009. pp.46-106.
