Methanol Electro-Oxidation Using RuRh@Pt/C

Abstract:

A core-shell structure RuRh@Pt/C nanoparticles was prepared by using a two-step reduction method under ultrasonic promotion. The catalytic performance was tested in methanol electrooxidation. X-ray diffraction (XRD), scanning electron microscope (SEM) combined with cyclic voltammetry (CV) were used to characterize the obtained catalyst. The results showed that there was no alloy formed between the core RuRh and the shell Pt. The electrocatalytic activity of RuRh@Pt/C varied with the Ru/Rh ratio in the bimetallic core, among which the catalyst with the Ru/Rh ratio 1:2 and the Pt-shell thickness of 1.5 (Ru1Rh2@Pt1.5/C) showed the highest catalytic activity for methanol. With this catalyst, the current density of the oxidation peak for methanol electro-oxidation reached 2.3 times as that of Pt1.5/C while the corresponding peak potential shifted 60 mV negatively in comparing to that of Pt1.5/C. In addition, the catalyst with the core-shell structure of RuRh@Pt/C possessed much higher CO-tolerance for methanol electro-oxidation, indicating its promising application in low temperature fuel cell.

• Periodical: Advanced Materials Research (Volumes 953-954)
• Pages: 1297-1302
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.953-954.1297
• Online since: June 2014
• Authors: Guang Ying Wang, Li Fang, Fei Fei Li, Surin Saipanya
• Keywords: Core-Shell Structure, Electrochemical Oxidation, Ethanol, Rh@Pt/C

References

[1] D. J. Guo, Z. H. Jing. A novel co-precipitation method for preparation of Pt-CeO2 composites on multi-walled carbon nanotubes for direct methanol fuel cells, J. Power Sources, 2010, 195(12): 3802-3805.

DOI: 10.1016/j.jpowsour.2009.12.115

[2] H. Du, B. Li, F. Kang, R Fu, Y Zeng. Carbon aerogel supported Pt-Ru catalysts for using as the anode of direct methanol fuel cells, Carbon, 20007, 45(2): 429-435.

DOI: 10.1016/j.carbon.2006.08.023

[3] S. Chen, F. Ye, W. Lin. Carbon nanotubes-Nafion composites as Pt-Ru catalyst support for methanol electro-oxidation in acid media, Journal of Natural Gas Chemistry, 2009, 18(2): 199-204.

DOI: 10.1016/s1003-9953(08)60108-5

[4] J. R. C. Salgado, R. G. Duarte, L. M. IIharco A. M. Botelho do Rego, A. M. Ferraria, M. G. S. Ferreira. Effect of functionalized carbon as Pt electrocatalyst support on the methanol oxidation reaction, Applied Catalysis B: Environmental, 2011, 102 (3-4): 496-504.

DOI: 10.1016/j.apcatb.2010.12.031

[5] Y. P. Sun, L. Xing, K. Scott. Analysis of the kinetics of methanol oxidation in a porous Pt-Ru anode, J. Power Sources, 2010, 195 (1): 1-10.

DOI: 10.1016/j.jpowsour.2009.07.028

[6] K. Han, J. Lee, H. Kim. Preparation and characterization of high metal content Pt-Ru alloy catalysts on various carbon blacks for DMFCs, Electrochimica Acta, 2006, 52 (4): 1697-1702.

DOI: 10.1016/j.electacta.2006.03.098

[7] S. Wasmus, A. Küver. Methanol oxidation and direct methanol fuel cells: a selective review, Journal of Electroanalytical Chemistry, 1999, 461 (1-2): 14-31.

DOI: 10.1016/s0022-0728(98)00197-1

[8] K. Matsuoka, Y. Iriyama, T. Abe, M. Matsuoka, Z. Ogumi. Alkaline direct alcohol fuel cells using an anion exchange membrane, J. Power Sources, 2005, 150: 27-31.

DOI: 10.1016/j.jpowsour.2005.02.020

[9] W. M. Chen, G. Q. Sun, Z. X. Liang, Q. Mao, H. Q. Li, G. X. Wang, Q. Xin, H. Chang, C. Pak, D. Seung. The stability of a PtRu/C electrocatalyst at anode potentials in a direct methanol fuel cell, Journal of Power Sources, 2006, 160 (2006), p.933.

DOI: 10.1016/j.jpowsour.2006.02.069

[10] X. W. Li, J. Y. Liu, Q. H. Huang, W Vogel, D. L. Akins, H. Yang. Effect of heat treatment on stability of gold particle modified carbon supported Pt–Ru anode catalysts for a direct methanol fuel cell, Electrochimica Acta, 2010, 56 (1): 278-284.

DOI: 10.1016/j.electacta.2010.08.083

[11] P. Piela, C. Eickes, E. Brosha, F. Garzon, P. Zelenay. Ruthenium Crossover in Direct Methanol Fuel Cell with Pt-Ru Black Anode, J. Electrochem. Soc, 2004, 151: 2053-(2059).

DOI: 10.1149/1.1814472

[12] N. Tsiouvaras, M. V. MartÍnez-Huerta, O. Paschos, U. Stimming, J. L. G. Fierro, M. A. Peňa. PtRuMo/C catalysts for direct methanol fuel cells: Effect of the pretreatment on the structural characteristics and methanol electrooxidation, International journal of hydrogen energy, 2010, 35(20): 11478-11488.

DOI: 10.1016/j.ijhydene.2010.06.053

[13] Y. C. Zhao, Y. Cai, J. Tian, H. Lan. Facile preparation and excellent catalytic performance of PtRuPd hollow spheres Nanoelectrocatalysts, Materials Chemistry and Physics, 2009, 115: 831-834.

DOI: 10.1016/j.matchemphys.2009.02.048

[14] L. Fang, F. J. Vidal-Iglesias, S. E. Huxter, G. A. Attard. A study of the growth and CO electrooxidation behaviour of PtRh alloys on Pt{100} single crystals, Journal of Electroanalytical Chemistry, 2008, 622 (1): 73-78.

DOI: 10.1016/j.jelechem.2008.05.003

[15] R. Gómez, F. Javier Gutiérrez de Dios, J. M. Feliu. Carbon monoxide oxidation and nitrous oxide reduction on Rh/Pt (111) electrodes, Electrochimica Acta, 2004, 49: 1195-1208.

DOI: 10.1016/j.electacta.2003.07.014

[16] R. Gómez, J. M. Feliu. Rhodium adlayers on Pt(111) monocrystalline surfaces. Electrochemical behavior and electrocatalysis, Electrochimica Acta, 1998, 44 (6-7): 1191-1205.

DOI: 10.1016/s0013-4686(98)00222-9

[17] J. H. Choi, K. W. Park, I. S Park, W. H. Nam, Y. E. Sung. Methanol electro-oxidation and direct methanol fuel cell using Pt/Rh and Pt/Ru/Rh alloy catalysts, Electrochimica Acta, 2004, 50 (2-3): 787-790.

DOI: 10.1016/j.electacta.2004.01.109

[18] Z. Liu, X. Y. Ling, X. Su, J. Y. Lee. 2004. Carbon-Supported Pt and PtRu Nanoparticles as Catalysts for a Direct Methanol Fuel Cell, J. Phys. Chem. B, 108: 8234-8240.

DOI: 10.1021/jp049422b
