A Low Phase Noise and Low Spurious Frequency Source based on Programmable Frequency Dividers

Abstract:

In this paper, based on the programmable frequency dividers HMC394 and AD company's integer PLL chip ADF4107, in the premise of not reducing the phase detector frequency, improved the frequency resolution and effectively inhibits the phase stray. Designed a frequency source with high performance index: high resolution is 10kHz, low phase noise is-91.27dBc/Hz @10kHz, low spurious is less than-60dBc, high harmonic suppression is less than-60dBc,the design method is simple, low cost, flexible control, high performance and widely used.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 310-313
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.310
• Online since: June 2014
• Authors: Chen Liang*
• Keywords: Frequency, High Frequency Resolution, High Harmonic Suppression, Low Phase Noise, Low Spurious, Phase Detector, Phase Stray, PLL, Programmable Frequency Divider

References

[1] T.H. Lee and J.F. Bulzacchelli, A 155-MHz clock recovery delay-and phase-locked loop, IEEE J. of Solid-State Circuits[J] . 1992, 27(12): 1736-1746.

DOI: 10.1109/4.173100

[2] Puglia，KV . phase noise analysis of component cascade Microwave Magazine[J] . IEEE, 4(3): 71-75.

[3] RiehardKarlquist. A Narrow Band High-Resolution Synthesizer Using A Direct Digital Synthesizer Followed by Repeated Dividing and Mixing IEEE International Frequency Control Sym Posium , 1995：217-235.

DOI: 10.1109/freq.1995.483906

[4] Teresa M. Almeida, Moises S. Piedade. High performance analog and digital PLL design. IEEE, 1999, Ⅳ-394-Ⅳ-397.
