Analysis of Packer Rubber Mechanics Properties

Abstract:

Abstract: The packer rubber stress in the bottom hole is more complex. Based on constitutive model of the packer rubber material, this paper determines such parameters as model constants, Poisson's ratio of rubber materials and elastic modulus by using experimental method, to build up the finite element model of center tube-rubber cylinder-casing for the purpose of stress analysis. Finally, the distribution regularity of rubber cylinder-casing contact stress and packer setting travel distance with varying loads is concluded. The results can provide the theoretical basis for further analysis of packer rubber sealing performance.
