PZT Dielectric Ceramic Characterization for Application in Nonlinear Transmission Lines

Abstract:

Nonlinear dielectric lines have been tested for use in RF generation. Although they have presented a reasonable success in the frequency range between 250 and 400 MHz, their main limitation is the dielectric losses of barium titanate (BT) tiles used as nonlinear medium in these lines, which prevents from achieving higher frequencies. The solution for this appears to be the search for a new dielectric. Herein, we are proposing the use of a piezoelectric titanate-based ceramics known as PZT (lead zirconate titanate), which appears to have lower dielectric losses than BT slabs. In this paper, loss characterization tests of the PZT ceramics are compared with BT in the MHz frequency range. Also, we have investigated and compared the nonlinearity properties of the dielectrics by varying the DC applied voltage and temperature.

• Periodical: Advanced Materials Research (Volume 975)
• Pages: 23-28
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.975.23
• Online since: July 2014
• Authors: Lauro Paulo Silva Neto*, Jose O. Rossi
• Keywords: Capacitors, Dielectric, Losses, Nonlinearity, Permittivity, PZT Ceramics

References

[1] J.O. Rossi, L.P. Silva Neto, F.S. Yamasaki and J.J. Barroso, State of the art of nonlinear transmission lines for applications in high power microwaves, Proc. SBMO/IEEE MTT-S Int. Microwave and Opt. Conf., RJ, Brazil (2013).

DOI: 10.1109/imoc.2013.6646475

[2] N.S. Kuek, A.C. Liew, E. Schamiloglu, J.O. Rossi, Pulsed RF oscillations on a nonlinear capacitive transmission line, IEEE Trans. Dielectr. Electr. Insul. 20, 4 (2013) 1129-1135.

DOI: 10.1109/tdei.2013.6571427

[3] H. Ikezi, J.S. DeGrassie, J. Drake, Soliton generation at 10 MW level in the very high frequency band, Appl. Phys. Lett. 58 (1991) 986-987.

DOI: 10.1063/1.104464

[4] D.M. French, B.W. Hoff, S. Heidger, D. Shiffler, Dielectric nonlinear transmission line, Proc. IEEE Int. Pulsed Power Conf., Chicago, USA (2011) 341-345.

DOI: 10.1109/ppc.2011.6191441

[5] E. Defaÿ, T. Lacrevaz, T.T. Vo, V. Sbrugnera, C. Bermond, M. Aïd, B. Fléchet, Ferroelectric properties of Pb(Zr, Ti)O3 thin films until 40 GHz, Appl. Phys. Lett. 94, 052901 (2009).

DOI: 10.1063/1.3072348

[6] J.O. Rossi, L.P. Silva Neto, F.S. Yamasaki, E. Schamiloglu, Prospects of building capacitive nonlinear lines using PZT for high-frequency operation, Proc. IEEE Int. Power Mod. HV Conf., San Diego, CA, USA (2012) 752-755.

DOI: 10.1109/ipmhvc.2012.6518854

[7] L.P. Silva Neto, J.O. Rossi, A.R. Silva Junior, Characterization of dielectric properties of commercial ceramic capacitors for pulsed power applications, Proc. Braz. Power Electron. Conf., RN, Brazil (2011) 347-351.

DOI: 10.1109/cobep.2011.6085283

[8] M.P. McNeal, S.J. Jang, R. E. Newnham, The effect of grain and particle size on microwave properties of barium titanate (BaTiO3), J. Appl. Phys. 83, (1998) 3288.

DOI: 10.1063/1.367097

[9] L.P. Silva Neto, J.O. Rossi, J.J. Barroso, A.R. Silva, P.J. Castro, P.A.G. Dias, Characterization of ceramic dielectrics for sub-GHz applications in nonlinear transmission lines, Proc. SBMO/IEEE MTT-S Int. Microwave and Opt. Conf., RJ, Brazil (2013).

DOI: 10.1109/imoc.2013.6646601
