Analysis to Milling Force Base on AdvantEdge Finite Element Analysis

Abstract:

Aiming at NC milling processing simulation problem, a ball-end cutter milling force model is established, the numerical simulation analysis of aluminum alloy AL2024 milling process is conducted by using the finite element analysis software AdvantEdge finite element analysis. Focus on the Milling force simulation, the size of the milling force is obtained by simulating calculation. Using the same cutting parameters for milling experiment, the results show that simulation analysis of the cutting force values ​​are in good agreement with the experimental results，the milling force model prior established is correct. The research laid a foundation for the perfect CNC milling simulation system.

• Periodical: Advanced Materials Research (Volume 981)
• Pages: 895-898
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.981.895
• Online since: July 2014
• Authors: Fu Cai Zhang*, Qing Wang, Ru Yang
• Keywords: Experimental Verification, Finite Element Analysis (FEA), Milling Force Modeling, Spherical Milling Cutter
