Bundle Conductors Corona Current Harmonic Wave Measurement

Abstract:

In order to research high level harmonic wave of six bundle conductors corona current, a measurement system was developed, and a series of wave data was obtained. Corona current is one of important corona characteristic research contents. The corona current measurement system can be used to measure the wide frequency band corona current. Six-bundle conductors was tested, and corona current was obtained. And the current signal collected in this way is safe and reliable. To research the six-bundle conductors’ corona current characteristic, conductor corona current harmonic wave was analyzed, by advanced Hanning windowed interpolation FFT algorithm was adopted. Corona current harmonic characteristics before and after corona onset were compared. Research results show that, after corona onset, corona current odd harmonic increases in evidence, and even-order harmonic increase less relatively. Triple-frequency harmonics and quintuple harmonics increase obviously very much.

• Periodical: Advanced Materials Research (Volumes 986-987)
• Pages: 1466-1470
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.986-987.1466
• Online since: July 2014
• Authors: Shao Hua You*, Li Chen, Jie Huang, Yun Peng Liu, Fang Cheng Lü
• Keywords: Conductor, Corona Current, FFT, Hanning Window, Harmonic Wave

References

[1] Clade J J, Gary C H: Predetermination of corona losses under rain: experimental interpreting and checking of a method to calculate corona losses. IEEE Trans on PAS, vol. 89 (1970) no. 5, pp.853-860.

DOI: 10.1109/tpas.1970.292648

[2] P Sarma Maruvada: Corona performance of high voltage transmission lines. London, UK: Research Studies Press Ltd (2000), pp.91-108.

[3] LI Shunyuan: The application of optical fiber to measure the high voltage transmission line corona loss. Power system technology, vol. 3(1987) no. 1, pp.1-9.

[4] MAO Yingke, GUAN Zhicheng, WANG Liming, et al.: Development of a Leakage Current Monitoring System for Pollution Test Lab. High voltage apparatus, vol. 39(2003) no. 2, pp.94-96.

[5] M. Khalifa, M. Abdel-Salam: Improved method for calculating DC corona losses, IEEE Transactions on Power Apparatus and Systems, vol. 93(1974), no. 2, pp.720-726.

DOI: 10.1109/tpas.1974.294035

[6] WANG Nan, LU Fangcheng, LIANG Ying: Application of harmonics analysis approach based on modified ideal sampling frequency in on-line measuring tanδ. Electrical Measurement and Instrumentation, vol. 40(2003), no. 7, pp.12-15.

[7] WANG Nan, LU Fangcheng: Application of Wavelet Transform to Extract the Trend of tan δ On-line Monitoring. High Voltage Engineering, vol. 29(2003), no. 4, pp.31-33.

[8] YANG Xiao-dong, TANG Chao, LIAO Rui-jin: Improved Harmonic Analysis Methods for Measuring Dielectric Loss of Capacitive Equipment. High Voltage Apparatus, vol. 43(2007), no. 6, n. 460-462.
