A Novel Optoelectronic Oscillator with Series-Coupled Double Recirculating Delay Lines

Abstract:

An optoelectronic oscillator (OEO) based on series-coupled double recirculating delay lines (SC-DRDLs) is analyzed and experimentally demonstrated. The SC-DRDLs composed by the coupling cascade of two RDLs, which the free spectral range (FSR) is least common multiple of the two RDLs’ FSR, and then the large FSR can be obtained by properly setting the loop lengths of two RDLs. By consociation with the dual loops system between the dual output of the SC-DRDLs and PBS, the high sidemode suppression performance can be achieved. Meantime, the incoherence of the SC-DRDLs can be performed by using an amplified spontaneous emission (ASE) broadband laser source. An experiment is carried out. A microwave signal with high spectral purity, long-term stability, low single-sideband (SSB) phase noise is generated.

• Periodical: Advanced Materials Research (Volumes 986-987)
• Pages: 1730-1733
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.986-987.1730
• Online since: July 2014
• Authors: Cheng Xin Li*, Fu Shen Chen, Jing Yuan
• Keywords: Microwave Generation, Microwave Photonic Filter (MPF), Optoelectronic Oscillator (OEO), Series-Coupled Double Recirculating Delay Lines (SC-DRDLs)

References

[1] X. S. Yao and L. Maleki: Optoelectronic microwave oscillator. J. Opt. Amer. B, Vol. 13 (1996), pp.1725-1735.

[2] H. Tsuchida: Simultaneous prescaled clock recovery and serial-to-parallel conversion of data signals using a polarization modulator-based optoelectronic oscillator. J. Lightw. Technol., Vol. 27 (2009), p.3777–3782.

DOI: 10.1109/jlt.2009.2025396

[3] M. Shin and P. Kumar: Optical microwave frequency up-conversion via a frequency-doubling optoelectronic oscillator. IEEE Photon. Technol. Lett., Vol. 19 (2007), p.1726–1728.

DOI: 10.1109/lpt.2007.905669

[4] X. S. Yao and L. Maleki: Multiloop optoelectronic oscillator. IEEE J. Quantum Electron, Vol. 36 (2000), pp.79-84.

DOI: 10.1109/3.817641

[5] W. M. Zhou and G. Blasche: Injection-locked dual opto-electronic oscillator with ultra-low phase noise and ultra-low spurious level. IEEE Trans. Microw., Theory Tech., Vol. 58 (2005), p.929–933.

DOI: 10.1109/tmtt.2004.842489

[6] Jiang Yang, Yu Jinglong, Wang Yaotian, Zhang Litai, and Yang Enze: An optical domain combined dual-loop optoelectronic oscillator. IEEE Photon. Technol. Lett., Vol. 19 (2007), p.807– 809.

DOI: 10.1109/lpt.2007.897290

[7] E. Salik, N. Yu, L. Maleki: An ultralow phase noise coupled optoelectronic oscillator. IEEE Photon. Technol. Lett., Vol. 19 (2007), p.444–446.

DOI: 10.1109/lpt.2007.892907

[8] O. Pottiez, O. Deparis, R. Kiyan, M. Haelterman, P. Emplit, P. Mégret, M. Blondel: Supermode noise of harmonically mode-locked Erbium fiber lasers with composite cavity. IEEE J. Quantum Electron, Vol. 38 (2002), pp.252-259.

DOI: 10.1109/3.985565

[9] J. Capmany, B. Ortega, D. Pastor: A tutorial on microwave photonic filter. J. Lightw. Technol., Vol. 24 (2006), p.201–229.

DOI: 10.1109/jlt.2005.860478

[10] J Capmany: On the cascade of incoherent discrete-time microwave photonic filters. J. Lightw. Technol., Vol. 24 (2006), p.2564–2578.

DOI: 10.1109/jlt.2006.874606
