The New Technology of PV Power Generation System Based on Extremum Seeking Control

Abstract:

A novel is based on a simplified two-diode model of photovoltaic (PV) module,which can more accurately predict the output characteristic of the solar cells I-U curve. On this basis, Aiming at promptness and stability tracking the maximum power point of the photovoltaic cells under the conditions of the constant temperature and light intensity, a novel control strategy based on sliding mode based extremum seeking control (SM-ESC) system for optimally tracking the maximum power point of the photovoltaic cells is proposed.To achieve higher control quality, an adaptive adjustment method is further presented on the basic of stabilizing conditions of SM-ESC system, avoiding complicated manually parameter adjustment.Thus photovoltaic system can quickly stabilize at the maximum power point, less volatile when tracking the optimum output curve. Simulation results show the effectiveness and validity of the control strategy and adjustment method proposed .

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 1185-1188
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.1185
• Online since: July 2014
• Authors: Ji Ying Shi*, Kai Zhang, Yong Ge Zhang
• Keywords: Adaptive Parameters Adjustment, Maximum PV Energy Tracking, RTDs, SM-ESC

References

[1] Kuo Y.C.; Liang, T.J. Novel maximum-power-point-tracking controller for photovoltaic energy conversion system. IEEE Trans. Ind. Electron. 2002, 48, 594–601.

DOI: 10.1109/41.925586

[2] Liu, F.; Duan, S.F.; Liu, B.; Kang, Y. A variable step size INC MPPT method for PV systems. IEEE Trans. Ind. Electron. 2008, 55, 2622–2628.

DOI: 10.1109/tie.2008.920550

[3] Cesare, G.D.; Caputo, D.; Nascetti, A. Maximum power point tracker for portable photovoltaic systems with resistive-like load. Sol. Energy 2006, 80, 982–988.

DOI: 10.1016/j.solener.2005.07.010

[4] Wen, F.; Diao, Z.; Chao, Y.; Mo, R. The Design and Implementation of Photovoltaic Grid-connected Simulating Device Based on FPGA. In Proceedings of the IEEE Power and Energy Engineering Conference, Chengdu, China, 28–31 March (2010).

DOI: 10.1109/appeec.2010.5448886

[5] Benmessaoud, M.T.; Zerhouni, F.Z.; Zegrar, M.; Stambuli, A.B.; Tioursi, M. New approach modeling and a maximum power point tracking method for solar cells. Comput. Math. Appl. 2010, 60, 1124–1134.

DOI: 10.1016/j.camwa.2010.04.001

[6] KUROBE K，MATSUNAMI H. New two-diode model for detailed analysis of multicrystalline silicon solar Cells［J］. Appl Phys, 2005( 44) : 8314-8321.

DOI: 10.1143/jjap.44.8314

[7] KARTIK B. ARIYUR, MIROSLAV KRSTIC´, Real-Time Optimization by Extremum-Seeking Control[M] , Canada, (2003).

[8] Yaodong Pan , Ümit Özgüner, Tankut Acarman . Stability and performance improvement of extremum seeking control with sliding mode[J]. International Journal of Control, 2003, VOL. 76, NOS 9/10, 968–985.

DOI: 10.1080/0020717031000099100
