Research on the Processing Simulation of Whorl Milling Based on LISP

Abstract:

According to the development requirements of CAD/CAM numerical control processing simulation software, now take the simulation of milling whorl processing as an example. Based on AutoCAD application platform, and the theory of whorl milling processing, LISP is used for programming, and the simplified ball three-dimensional entity model of the disc cutter is shown. Through object boolean operation, the milling simulation program is called, finally realizing the dynamic 3D simulation of whorl milling processing, providing technical support for the real-time observation of numerical control milling.

• Periodical: Advanced Materials Research (Volumes 998-999)
• Pages: 466-469
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.998-999.466
• Online since: July 2014
• Authors: Ying Zhang, Xin Shi*
• Keywords: 3D Simulation, Disc Cutter, LISP, Milling Whorl, Numerical Control

References

[1] ZHOU Jing, WANG Xin-hua. Research on the simulation for NC turning[J]. Machinery Design & Manufacture, 2008(7): 155-157.

[2] MU Li-sha. Simulation of Macro Programs of Trapezoidal Whorl[J]. Mechanical Engineering & Automation, 2012(3): 177-179.

[3] Wei Fang. 3D Simulation of Whorl Based on AutoCAD[J]. Science Mosaic, 2006(4): 67-68.

[4] Wei Ping, Geng Huilian. Macro Programs Design of NC Turning Acme Screw Whorl Based on VERICUT[J]. Tool Engineering, 2010, 44(2): 80-82.

[5] Li Yue-wu. 3D Simulation of Whorl Processing Based on AutoCAD[J]. Modern Manufacturing, 2005(2): 125-126.
