Analysis of Three Dimensional Nonlinear Coupled Finite Element Based on some Concrete Rock-Fill Dam

Abstract:

As the future highest dam in the world, Shuang Jiang Kou rock-fill dam was the water retaining structure of homonymous hydropower station, a controlling engineering on Da Du River hydropower development, which is under design now. This dam is a central earth core dam with a height of 312 meters. A type of gravel soil stiffer than clay, which is made by artificial compounding of clay and gravel, is introduced to reduce the difference in displacement of earth core and rock filled shell zone. Because of the introduced less flexible central core, a more remarkable arching effect of the abutment on earth core might occur simultaneously. A three dimensional coupled nonlinear finite element analysis is carried out to study the three dimensional arching effect of Shuang Jiang Kou rock-fill dam. Computation results show that the arching effect is much notable. Then an innovation is proposed in design, in which a contact high-plasticity clay layer is introduced. It is verified that this innovation is effective and necessary.

You might also be interested in these eBooks

Advances in Applied Sciences, Engineering and Technology II

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 998-999)

Pages:

522-525

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.998-999.522

Citation:

Cite this paper

Online since:

July 2014

Authors:

Juan Juan Jin*, Min He, Peng Liu

Keywords:

Arching Effect, Finite Element Analysis (FEA), High-Plasticity Clay, Narrow Valley, Rock-Fill Dam, Three Dimension

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Alberro, J., and Moreno, E., 1982. Interaction phenomena in the Chicoasen dam: construction and first filling. 14th ICOLD, Rio de Janeiro. V I，Q 52, R 10: 183-202.

Google Scholar

[2] Biot. M. A., 1956. Theory of elastic waves in a fluid-saturated porous solid, II . High-Frequency Range. J. Acoust. Soc. Am. ，28: 179-191.

DOI: 10.1121/1.1908241

Google Scholar

[3] Duncan, J. M., Chang C. Y, 1970. Nonlinear analysis of stress and strain in soils, J. SMFD, ASCE, Vol. 96, No. SMS, p.1629.

Google Scholar

[4] Duncan, J. M，et al., 1980. Strength, stress-strain and bulk modulus parameters for finite element analysis of stress and movement in soil masses, Report No. UCB/GT/80-01, University of California, Berkeley.

Google Scholar

[5] Hilf, J.W., 1949. Estimating construction pore pressure in rolled earth dams, in Proceedings of the 2nd International Conference on Soil Mechanics and Foundation Engineering. Rotterdam, Vol. 3: 234-240.

Google Scholar
