Thermal Schock Criteria of Refractory Ceramics: Limitations of Conventional Analyses and Some Numerical Approaches to Improve the Prediction of the Resistance to Thermal Schock

Abstract:

Significant advances in the mechanical design of ceramic parts were realized since the pioneer works of Kingery and Hasselman to define thermal shock resistance. But for high heterogeneous refractories and contrasted local phase properties the use of these criteria is not always convincing because the assumptions made are too simplicist. First, we underline how thermal shock resistance parameters helped to improve the global performance of ceramics and make some comments on their limitations for refractory materials. Then we show how numerical tools are useful for the design of refractory structures at high temperatures through several approaches we have developed for refractory structures: prediction of macroscopic thermal shock resistance of heterogeneous refractories using multi-scale analysis, finite element methods applied to a specific structure considering either a two-scale approach to describe the thermo-elastic quasi brittle behavior of heterogeneous materials, at the macroscopic scale approach considering homogeneous microstructure.

• Periodical: Advances in Science and Technology (Volume 70)
• Pages: 160-166
• DOI: https://doi.org/10.4028/www.scientific.net/AST.70.160
• Online since: October 2010
• Authors: Nicolas Schmitt
• Keywords: Refractory Ceramic, Thermal Shock Resistance, Thermomechanics

References

[1] W. Lee and R. Moore: J. am. Ceram. Soc., Vol. 81 (1998), p.1385.

[2] B.A. Boley and J.H. Weiner: Theory of thermal stresses, edited by J. Wiley & Sons, Inc. New York (1960).

[3] W.D. Kingery: J. am. Ceram. Soc., Vol. 38 (1955), p.3.

[4] D.P.H. Hasselman: J. am. Ceram. Soc., Vol. 52 (1963), p.600.

[5] W.D. Kingery and al. H.K. Bowen and D.R. Uhlmann: Introduction to ceramics 2nd Ed., edited by J. Wiley & Sons, Inc. New York (1976).

[6] S.S. Manson and R.W. Smith: J. Am. Ceram. Soc., Vol. 38.

[1] (1955), p.18.

[7] T.J. Lu and N.A. Fleck: Acta Materialia, Vol. 46 (1998), p.4755.

[8] Z. Zhou, P. Ding, S. Tan and J. Lan: Mat. Sci. Eng. A, Vol. 405 (2005), p.272.

[9] M.F. Ashby: Materials selection and process in mechanical design, ed. by Butterworth Heinemann, Oxford (1999).

[10] N. Schmitt, A. Burr, Y. Berthaud and J. Poirier: Mech. of Materials, Vol. 34 (2002), p.725.

[11] T. Miloh and Y. Benveniste: J. Appl. Phys., Vol. 63.

[3] (1988), p.789.

[12] G. Siboni and Y. Benveniste: Mech. Mat., Vol. 11, p.107.

[13] S. Peruzzi, PhD.: Thesis University of Limoges, France (2000).

[14] A. Gasser, P. Boisse, J. Rousseau, Y. Dutheillet: Comp. Sci. Tech., Vol. 61 (2001), p. (2095).

[15] D. Gruber, K. Andreev and H. Harmuth: J. Mat. Proc. Tech. Vols. 155-156 (2004), p.1539.

[16] E. Damhof: PhD. Thesis, Eindhoven University Technology, The Netherlands (2010).

[17] E. Arfan, N. Schmitt, E. Lamblin and C. Perrot: Proc. 2th Int. Cong. Ceramics, Verona Italy, June 29-July 4 (2008).

[18] R. H. J. Peerlings, R. De Borst W. A. M. Brekelmans and J.H.P. De Vree: J. Mat. Civil Engng. Vol. 17.

[3] (2005), p.3391.

[19] N. Moës, J. Dolbow and T. Belytschko: Int. J. Numer. Meth. Engng. Vol. 46 (1999), p.131.

[20] Hibbitt, Karlsson and Sorensens: Abaqus 6. 5, Hibbitt, Karlsson and Sorensens Inc. Pawtucket, RI (2009).

[21] N. Schmitt, E. Blond and F. Hild, Advances in refractories for the metallurgical industries IV, Edited by M. Rigaud and C. Allaire (2004), p.39.

[22] K. Madi, S. Forest, M. Boussuge, S. Gailliegue, E. Lastate, J.Y. Buffière, D. Besnard and D. Gelin: Comp. Mat. Sci. Vol. 39 (2007), p.224.

[23] R.H.J. Peerlings, M.G.D. Geers, R. de Borst and W.A.M. Brekelmans: Int. J. Solids. Structures, Vol. 38 (2001), p.7723.
