2D Flow in a Wall-Bounded Porous Medium

Abstract:

A compact finite differences method is used to calculate two-dimensional viscous flows through complex geometries. The immersed boundaries are set through body forces that allow for the imposition of boundary conditions that coincide with the computational grid. Two different flow configurations are simulated. First, the flow through a row of cylinders with square cross-sections is calculated and used as a validation study. The computed average drag coefficient and Strouhal number are compared to data available in the literature, showing a good agreement between the results. The second flow configuration analyzed is the flow through a porous matrix composed of equal size staggered square cylinders. Flow visualization results are shown and various flow regimes identified. Different inlet boundary conditions are compared. The drag coefficient is larger when a uniform inlet velocity is prescribed and the variability between cylinders is lower.

• Periodical: Defect and Diffusion Forum (Volumes 334-335)
• Pages: 359-364
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.334-335.359
• Online since: February 2013
• Authors: P.J.S.A. Ferreira de Sousa, Isabel Malico, Gérson Fernandes
• Keywords: Immersed Boundary Method, Incompressible Flow, Porous Medium, Square Cylinder

References

[1] M.N. Musta and P.S. Krueger, in: Proceedings of the 4th International Conference on Applications of Porous Media, Istanbul, Turkey (2009).

[2] M. Sahraoui and M. Kaviany: Int. J. Heat Mass Transf. Vol. 37 (1994), p.2817.

[3] M.H.J. Pedras and M.J.S. de Lemos: Int. J. Heat Mass Transf. Vol. 44 (2001), p.1081.

[4] W.P. Breugem and B.J. Boersma: Phys. Fluids Vol. 17 (2005), p.025103.

[5] A.A. Alshare, P.J. Strykowski and T.W. Simon: Int. J. Heat Mass Transf. Vol. 53 (2010), p.2294.

[6] E.J. Braga and M.J.S. de Lemos: Int. Commun. Heat Mass Transf. Vol. 32 (2005), p.1289.

[7] Z. Chai, B. Shi, J. Lu and Z. Guo: Comput. Fluids Vol. 39 (2010), p. (2069).

[8] D.J. Lopez Penha, B.J. Geurts, S. Stolz and M. Nordlund: Comput. Fluids Vol. 51 (2011), p.157.

[9] A. Nakayama, F. Kuwahara and T. Hayashi: J. Fluid Mech. Vol. 498 (2004), p.139.

[10] R. Mittal and G. Iaccarino: Ann. Rev. Fluid Mech. Vol. 37 (2005), p.239.

[11] J. Mohd-Yusof: Combined Immersed Boundaries/B-Splines Methods for Simulations of Flows in Complex Geometries (CTR Annual Research Briefs 1997).

[12] P.J.S.A. Ferreira de Sousa, J.C.F. Pereira and J.J. Allen: Int. J. Numerical Meth. Fluids Vol. 65 (2011), p.609.

[13] M. Breuer, J. Bernsdorf, T. Zeiser and F. Durst: Int. J. Heat Fluid Flow Vol. 21 (2000), p.186.

[14] P.J.S.A. Ferreira de Sousa, I. Malico and G. Fernandes: Defect Diffus. Forum, Vols. 326-328 (2012), p.725.

[15] S.R. Kumar, A. Sharma and A. Agrawal: J. Fluid Mech. Vol. 606 (2008), p.369.

[16] D. Chatterjee, G. Biswas and S. Amiroudine: Comput. Fluids Vol. 39 (2010), p.49.
