On the Mechanism of Oxidation Resistance of W-Cr-Pd Alloys

Abstract:

While studying activation sintering of tungsten, Evans [5] and Ito and Furusawa [6] revealed that W-Cr-Pd alloys exhibit unexpected oxidation resistance at elevated temperatures. The role of palladium in stimulating oxidation resistance in W-Cr alloys is the main aim of the present contribution. As previously observed, at 800 °C these alloys form a relatively dense protective scale that consists of an inner layer of Cr₂O₃, an intermediate layer of Cr₂WO₆ and an external layer of WO₃. At 1200 °C only Cr₂WO₆ layer is found, since the Cr₂O₃ and WO₃ evaporate. To determine the role of paladium, W and W-Pd alloys were coated with Cr layers and undergone diffusion experiments. An extraordinary affinity between the Cr and Pd was revealed, manifested by extremely fast inward diffusion of Cr along grain boundaries. In a second experiment the dissolution of Cr into W grains at 1300°C was followed and found to take place preferentially along grain boundaries. These observations assess that the Pd segregated at grain boundaries provides fast diffusion channels for Cr to the free surface and it imparts the significant improvement of the oxidation resistance of W alloys, as suggested by Lee and Simkovitz [10-12].

• Periodical: Defect and Diffusion Forum (Volume 383)
• Pages: 133-141
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.383.133
• Online since: February 2018
• Authors: Alon Kafri, Alexandra Makonovitsky, Roni Z. Shneck*
• Keywords: Fast Diffusion, Oxidation, Refractory Metals

References

[1] Y. Muramatsu and T. Takeda, Effect of Pd addition on the oxidation characteristics of W-CR sintered alloys, Trans. of National Research Institute for Metals (Jpn), 24 (1982) 15-14.

[2] S. Diliberto, C. Rapin, P. Steinmetz, M. Vilasi and P. Berthod, Development of chromia forming Mo-W-Cr alloys: synthesis and characterization, J. Mater. Sci., 37 (2002) 3277-3284.

DOI: 10.1023/a:1016191202525

[3] S. Telu, A. Petra, M. Sankaranarayana, R. Mitra and S.K. Rabi, Microstructure and cyclic oxidation behavior of W-Cr alloys prepared by sintering of mechanically alloyed nanocrystalline powders, Int. J. Refractory Metals and Hard Mater., 36 (2013).

DOI: 10.1016/j.ijrmhm.2012.08.015

[4] S. Telu, A. R. Mitra and S.K. Rabi, High temperature oxidation behavior of W-Cr –Nb alloys in the temperature range of 800-1200oC, Int. J. Refractory Metals and Hard Mater., 38 (2013) 47-59.

DOI: 10.1016/j.ijrmhm.2012.12.008

[5] D. S. Evans, in High Temperature Materials, 6th Plansee Seminar, Metallwerk Plansee, Austria, 1968 p.42.

[6] H. Ito and M. Furusawa, J. Jap. Soc. Powder and Powder Metallrgy, 16 (1969) 145.

[7] T. Itagaki and R. Yoda, Effects of Palladium on Oxidation Behavior of sintered Tungsten-Chromium-Palladium Alloys, Trans. of National Research Institute for Metals, 17 (1975) 163-169.

[8] Y. Muramatsu and T. Takedu, Effect of Pd addition on the oxidation characteristics of W-Cr sintered alloysTrans. of National Research Institute for Metals, 24 (1982) 15-21.

[9] S. Diliberto, C. Rapin, P. Steinmetz, M. Vilasi and P. Berthod, Oxidation of chromia forming molybdenum-tungsten based alloys, J. of Materials Science, 38 (2003) 2063-(2072).

DOI: 10.4028/www.scientific.net/msf.369-372.825

[10] D. Lee and G. Simkovich, The oxidation behavior of molybdenum and chromium alloys, J. Less common Metals, 31 (1989) L1-L5.

DOI: 10.1016/0022-5088(89)90159-8

[11] D. Lee and G. Simkovich, The oxidation behavior of molybdenum and chromium alloys, J. Less Common Metals, 34 (1990) 51-62.

[12] D. Lee and G. Simkovich, Oxidation resistant Mo-W-Cr-Pd alloys with palladium coatings, J. Less Common Metals 169 (1991) 19-23.

DOI: 10.1016/0022-5088(91)90231-r

[13] L. Ingemarsson, M. Halvarsson, K. Hellstrom, T. Jonsson, M. Sundberg, L.-G. Johansson, J.-E. Svensson, Oxidation behavior at 300-1000 degrees C of a (Mo,W)Si2-based composite containing boride , Intermetallics 18 (2010) 77–86.

DOI: 10.1016/j.intermet.2009.06.013

[14] I. Ya Dzykovich, V. V. Panichkina, V. V. Skorokhod and L. I. Shaiderman, Effect of Pd on diffusion processes in the system W-Cr, Sov. Powder Metall. Met. Ceram., 15 (1976) 151-153.

DOI: 10.1007/bf00793571

[15] Li, P. Li, H. Bian, N. Tang, Y. Koizumi and A. Chiba, The hot forging behavior and its effects on the oxidation behavior of W-Cr alloy, Corrosion Sci., 83 (2014) 367-374.

DOI: 10.1016/j.corsci.2014.03.005

[16] W. W. Webb, J.T. Norton and C.Wagner, Oxidation of tungsten.. 103, (1956), J. Electrochem. Soc., 107-111.

[17] ASM International Handbook Committee, electronic edition. ASM Handbook: Alloy Phase diagrams. (1992).
