Geometrical Evaluation of a Pair of Elliptical Tubes Subjected to a Flow with Forced Convection Heat Transfer

Abstract:

In the present work it is performed a study on the geometric evaluation of a pair of elliptical tubes subjected to external flow with forced convection by means of numerical approach. The objectives are the maximization of Nusselt number (Nu_D) and the minimization of drag coefficient (C_D). The degrees of freedom for the pair of tubes arrangement are: the ratio between the transverse pitch and characteristic length of tubes (S_T/D), where D = (A)^1/2, the ratio of the main and secondary axes of the elliptical tube (a/b) and the angle of incidence of the flow on the pair of tubes (α). The simulations were carried out considering two-dimensional forced convective flows, in the laminar regime and incompressible conditions. For all configurations, Reynolds and Prandtl numbers are constant, Re_D = 100 and Pr = 0.71. The Finite Volume Method (FVM) is used to solve conservation equations of mass, momentum and energy. The software Gmsh is used for creation of the geometries and generation of the meshes. Results showed that the degrees of freedom affected the fluid dynamic and thermal performance of the forced convective flow. According to the objectives outlined in this study, the best performance for the maximization of heat transfer was obtained when α = 0o, a/b = 1⁄2 and S_T/D = 3.5. In the case of the fluid dynamics study, the optimal result for C_D minimization occurred when α = 0o, a/b = 2.0 and S_T/D = 4.0. Thus, the optimal geometry will depend on the indicator performance where the problem is evaluated.

• Periodical: Defect and Diffusion Forum (Volume 396)
• Pages: 155-163
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.396.155
• Online since: August 2019
• Authors: Ana Paula Del Aghenese*, Eliander Manke Heinemann, Gabriel de Avila Barreto, Filipe Branco Teixeira, Liércio André Isoldi, Luiz Alberto Oliveira Rocha, Elizaldo Domingues dos Santos
• Keywords: Elliptical Tubes, Forced Convection, Geometrical Evaluation, Numerical Approach

References

[1] S. Kakaç, H. Liu, Heat Exchanger: Selection, Rating and Thermal Design. 2nd ed. New York. CRC Press, (2002).

[2] R.L.S. Mainardes, Optimization of Circular and Eliptical Finned Tubes Heat Exchangers in Turbulent Regime (in Portuguese). Energy and Thermal Sciences Doctorate Thesis, Universidade Federal do Paraná, (2007).

[3] A.L. Razera, Numerical Study of Heat Transfer Density Maximization in Laminar Flows over Elliptical Cylinders Using Constructal Design Method (in Portuguese), Mechanical Engineering Dissertation, Universidade Federal do Rio Grande do Sul, (2016).

DOI: 10.29289/2594539420190000419

[4] W.M. El-Maghlany, M.A. Alnakeeb, M.A. Teamah, M.M. Sorour, Experimental and Numerical Study of Laminar Mixed Convection from a Horizontal Isothermal Elliptic Cylinder. Int. J. Heat Mass Transf. 130 (2018) 116-127. https://doi.org/10.1016/j.ijthermalsci.2018.04.018.

DOI: 10.1016/j.ijthermalsci.2018.04.018

[5] R.S. Matos, J.V.C. Vargas, T.A. Laursen, A. Bejan, Optimally staggered finned circular and elliptic tubes in forced convection, Int. J. Heat Mass Transf. 47 (2004) 1347–1359, http://dx.doi.org/10.1016/j.ijheatmasstransfer.2003.08.015.

DOI: 10.1016/j.ijheatmasstransfer.2003.08.015

[6] T. Bello-Ochende, J.P. Meyer, O.I. Ogunronbi, Constructal multiscale cylinders rotating in cross-flow, Int. J. Heat Mass Transf. 54 (2011) 2568–2577, http://dx.doi.org/10.1016/j.ijheatmasstransfer.2011.02.004.

DOI: 10.1016/j.ijheatmasstransfer.2011.02.004

[7] T. Bello-Ochende, A. Bejan, Constructal multi-scale cylinders with natural convection, Int. J. Heat Mass Transf. 48 (2005) 4300–4306, http://dx.doi.org/10.1016/j.ijheatmasstransfer.2005.05.023.

DOI: 10.1016/j.ijheatmasstransfer.2005.05.023

[8] G.M. Barros, G. Lorenzini, L.A. Isoldi, L.A.O. Rocha, E.D. Dos Santos, Influence of mixed convection laminar flows on the geometrical evaluation of a triangular arrangement of circular cylinders, Int. J. Heat Mass Transf. 114 (2017) 1188–1200. http://dx.doi.org/10.1016/j.ijheatmasstransfer.2017.07.010.

DOI: 10.1016/j.ijheatmasstransfer.2017.07.010

[9] L.A.O. Rocha, M. das N. Gomes, A.F. Porte, M.M. Galarça, I.C. Acunha Jr., F.M.V. da Silva, L.A. Isoldi, E.D. Dos Santos, Constructal Design of Turbulent Forced Convective Flows over a Pair of Circular cylinders, in: Constr. Law Conf., Nanjing, 2013, p.174–184.

DOI: 10.5380/reterm.v11i1-2.62004

[10] F.B. Teixeira, G. Lorenzini, M.R. Errera, L.A.O. Rocha, L.A. Isoldi, E.D. dos Santos, Constructal Design of Triangular Arrangements of Square Bluff Bodies under Forced Convective Turbulent Flows, Int. J. Heat Mass Transf. 126 (2018) 521 – 535. https://doi.org/10.1016/j.ijheatmasstransfer.2018.04.134.

DOI: 10.1016/j.ijheatmasstransfer.2018.04.134

[11] L. Hermany, G. Lorenzini, R.J. Klein, F.F. Zinani, E.D. dos Santos, L.A. Isoldi, L.A.O. Rocha, Constructal Design Applied to Elliptic Tubes in Convective Heat Transfer Cross-Flow of Viscoplastic Fluids, Int. J. Heat Mass Transfer 116 (2018) 1054 – 1063. https://doi.org/10.1016/j.ijheatmasstransfer.2017.09.108.

DOI: 10.1016/j.ijheatmasstransfer.2017.09.108

[12] H.K. Versteeg, W. Malalasekera, An Introduction to Computational Fluid Dynamics: The Finite Volume Method, Pearson, (2007).

[13] H. Schlichting, 1979, Boundary-layer Theory, McGraw-Hill, New York.

[14] A. Bejan, Convection Heat Transfer, 4th Edition, Wiley, (2013).

[15] ANSYS. 14.0. – FLUENT User's Guide, ANSYS Inc., (2011).

[16] S.V. Patankar, Numerical Heat Transfer and Fluid Flow, McGraw Hill, New York, USA, (1980).
