Analysis of Forces on a Submarine Outfall by a RANS-VoF Numerical Wave Tank

Abstract:

Knowledge of forces due to the action of waves on submarine outfalls composed by a pipe and stabilizing concrete weights, considering the wave propagation direction to the outfalls, is essential to their design. 3D numerical models based on RANS-VoF (Reynolds-Average-Navier-Stokes Volume-of-Fluid) are able to estimate forces on the pipe and weights. The present study aims to simulate a submarine outfall with stabilizing concrete weights at 1:15 scale which was previously tested in the 3D Shallow Water Basin at the Danish Hydraulics Institute (DHI) to analyse the influence of the direction of the incident wave and the distance from the pipe to the bottom on the outfall forces. In this study, numerical results are compared with experimental ones for waves with four different amplitudes and with wave incidence perpendicular to the outfall. The use of k-ω SST turbulence model led to good agreement between numerical drag and lift forces and experimental ones, with a mean difference of 8.9 and 7.6%, respectively.

• Periodical: Defect and Diffusion Forum (Volume 396)
• Pages: 50-59
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.396.50
• Online since: August 2019
• Authors: Eric Didier*, Maria Graça Neves, Paulo R.F. Teixeira
• Keywords: Forces, Numerical Wave Tank, RANS-VoF, Submarine Outfalls

References

[1] A. Jarno-Druaux, A. Sakout, E. Lambert, Interference between a circular cylinder and a plane wall under waves, Journal of Fluids and Structures 9 (1995) 215-230.

DOI: 10.1006/jfls.1995.1011

[2] B.M. Sumer, J. Fredsøe, Hydrodynamics around cylindrical structures (Revised edition), Advanced Series on Ocean Engineering, 26, World Scientific, Singapore (2006).

DOI: 10.1142/6248

[3] M. Zhao, L. Cheng, A.H. Hongwei, A finite element solution of wave forces on a horizontal circular cylinder close to the sea-bed, Journal of Hydrodynamics, 18 (3 SUPPL) (2006) 139-145.

DOI: 10.1016/s1001-6058(06)60044-9

[4] F., Aristodemo, G.R. Tomasicchio, P. Veltri, New model to determine forces at on-bottom slender pipelines, Coastal Engineering, 3 (2010) 267-280.

DOI: 10.1016/j.coastaleng.2010.11.004

[5] M.G. Neves, P. Figueira, M.C. Afonso, A. Mendonça, M.V. Solis, E. Didier, M.T. Reis, M. Clavero, M. Ortega-Sánchez, M.A. Losada, Estudo experimental de forças sobre um emissário submarino: influência da direcção da agitação incidente, da presença dos aneis de estabilizaçção e da distância da conduta ao fundo, In Proccedings of 8as Jornadas Portuguesas de Engenharia Costeira e Portuaria, Lisbon (2013).

DOI: 10.11606/t.18.2008.tde-14102008-154437

[6] M.G. Neves, A. Mendonça, E. Didier, M.T. Reis, J. Inverno, P. Figueira, M.C. Afonso, M. Vílchez, M. Clavero, M. Ortega-Sánchez, M.A. Losada, Experimental study of forces on a submarine outfall: Influence of incident wave direction of stabilizing concrete weights and pipe distance from the bottom, HYDRALAB IV Joint User Meeting, Lisbon, (2014).

[7] Fluent 6.3, User's Guide, Fluent Inc, USA, 2006. Ansys (2016).

[8] C.W. Hirt, B.D. Nichols, Volume of fluid (VoF) method for the dynamics of free boundaries, Journal of Computational Physics 39 (1981) 201-225.

DOI: 10.1016/0021-9991(81)90145-5

[9] M. Peric, J.H. Ferziger, Computational Methods for Fluid Dynamics, second ed., Springer, (1997).

[10] P.R.F. Teixeira, D.P. Davyt, E. Didier, R. Ramalhais, Numerical simulation of an oscillating water column device using a code based on Navier Stokes equations, Energy 61(1) (2013) 513–530.

DOI: 10.1016/j.energy.2013.08.062

[11] H. Schäffer, G. Klopman, Review of multidirectional active wave absorption methods, J. Waterw. Port. Coast. Ocean Eng. 126 (2000) 88-97.

DOI: 10.1061/(asce)0733-950x(2000)126:2(88)

[12] J.L. Lara, A. Ruju, I.J. Losada, Reynolds averaged Navier-Stokes modelling of long waves induced by transient wave group on a beach, In Proceedings of R. Soc. A. 467 (2011) 1215-1242.

DOI: 10.1098/rspa.2010.0331

[13] E. Didier M.G. Neves, A Semi-Infinite Numerical Wave Flume using Smoothed Particle Hydrodynamics, IJOPE 22(3) (2012) 193-199.

[14] P. Higuera, J.L. Lara, I.J. Losada, Realistic wave generation and active wave absorption for Navier-Stokes models Application to OpenFOAM®, Coastal Engineering 71 (2013) 102-118.

DOI: 10.1016/j.coastaleng.2012.07.002

[15] E. Didier, P.R.F. Teixeira, M.G. Neves, A 3D numerical wave tank for coastal engineering studies, Defect and Diffusion Forum 372 (2016) 1-10.

DOI: 10.4028/www.scientific.net/ddf.372.1

[16] P.R.F. Teixeira, E. Didier, M.G. Neves, A 3D RANS-VOF wave tank for oscillation water column device studies, In Proccedings of VII International Conference on Computational Methods in Marine Engineering, MARINE 2017, Nantes (2017) 710-720.

[17] E. Didier, J.M. Paixão Conde, P.R.F. Teixeira, Numerical simulation of na oscillation water column wave energy converter with and without damping, In Proceedings of IV International Conference on Computational Methods in Marine Engineering, MARINE 2011, Lisbon (2011) 206-217.

[18] J.M. Paixão Conde, P.R.F. Teixeira, E. Didier, Numerical simulation of na oscillating water column wave energy converter: comparison of two numerical codes, In Proceedings of 21th International Offshore and Polar Engineering Conference, Maui (2011) 688-674.

[19] A. Mendonça, J. Dias, E. Didier, C.J.E.M. Fortes, M.G. Neves, M.T. Reis, J.M.P. Conde, P. Poseiro, P.R.F. Teixeira, An integrated tool formodelling OWC-WECs in vertical breakwaters: preliminary developments, J. Hydro-environment Research 19 (2017) 198-213.

DOI: 10.1016/j.jher.2017.10.007

[20] E. Didier, M.G. Neves, P.R.F. Teixeira, Análise das forças num emissário submarino utilizando um modelo numérico 3D RANS-VoF, In Proceedings of 5as Jornadas de Engenharia Hidrográfica, Lisbon (2018) 447-450.
