An Analytical Study to Compare the Heat Transfer Performances of Water-Based TiO₂, SiO₂, TiC and SiC Nanofluids

Abstract:

The thermophysical properties as well as the thermal performance of a nanofluid can be altered upon varying the nanoparticle type and/or nanoparticle volume concentration. Herein, the effects of variable nanoparticle concentration on water-based TiO₂, SiO₂, TiC, and SiC nanofluids have been studied analytically. The dispersion effects of 1-4% nanoparticle on the single-phase forced convection heat transfer performance of the nanofluids have been investigated. The effective thermophysical properties of the nanofluids are determined adopting the general correlations. The flow velocities of the nanofluids relative to their base fluids are assumed to be constant. Mouromtseff number has been employed as a convenient figure of merit to compare the nanofluids under fully developed internal laminar and turbulent flow conditions. The results indicate an increase in effective density, thermal conductivity, and dynamic viscosity of the nanofluids. Nanofluids containing carbide suspensions exhibit superior heat transfer properties compared to those having oxide suspensions.

• Periodical: Defect and Diffusion Forum (Volume 408)
• Pages: 119-128
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.408.119
• Online since: April 2021
• Authors: Md Yeashir Arafat*, Shashwata Chakraborty
• Keywords: Laminar Flow, Mouromtseff Number, SiC Nanofluid, SiO₂ Nanofluid, TiC Nanofluid, TiO₂ Nanofluid, Turbulent Flow

References

[1] S.U.S. Choi, Z.G. Zhang, P. Keblinski, Nanofluids, in: H.S. Nalwa (Ed.), Encyclopedia of Nanoscience and Nanotechnology, vol. 6, American Scientific Publishers, Los Angles, California, USA, 2004, 757–773.

[2] P. Keblinski, J.A. Eastman, D.G. Cahill, Nanofluids for thermal transport, Mater. Today 8 (2005) 36–44.

DOI: 10.1016/s1369-7021(05)70936-6

[3] Y. Hwang, J.K. Lee, J.K. Lee, Y.M. Jeong, S.I. Cheong, Y.C. Ahn, et al., Production and dispersion stability of nanoparticles in nanofluids, Powder Technol. 186 (2008) 145–153.

DOI: 10.1016/j.powtec.2007.11.020

[4] Y. Li, J. Zhou, S. Tung, E. Schneider, S. Xi, A review on development of nanofluid preparation and characterization, Powder Technol. 196 (2009) 89–101.

DOI: 10.1016/j.powtec.2009.07.025

[5] D. Wu, H. Zhu, L. Wang, L. Liu, Critical issues in nanofluids preparation, characterization and thermal conductivity, Current Nanosci. 5 (2009) 103–112.

DOI: 10.2174/157341309787314548

[6] W. Duangthongsuk, S. Wongwises, Measurement of temperature-dependent thermal conductivity and viscosity of TiO2-water nanofluids, Exp Therm. Fluid Sci. 33 (2009) 706–714.

DOI: 10.1016/j.expthermflusci.2009.01.005

[7] T.P. Teng, Y.H. Hung, T.C. Teng, H.E. Mo, H.G. Hsu, The effect of alumina/water nanofluid particle size on thermal conductivity, Appl. Therm. Eng. 30 (2010) 2213–2218.

DOI: 10.1016/j.applthermaleng.2010.05.036

[8] A. Nasiri, M. Shariaty-Niasar, A.M. Rashidi, R. Khodafarin, Effect of CNT structures on thermal conductivity and stability of nanofluid, Int. J. Heat Mass Transf. 55 (2012) 1529–1535.

DOI: 10.1016/j.ijheatmasstransfer.2011.11.004

[9] L.S. Sundar, M.K. Singh, A. Sousa, Investigation of thermal conductivity and viscosity of Fe3O4 nanofluid for heat transfer applications, Int. Commun. Heat Mass Transf. 44 (2013) 7–14.

DOI: 10.1016/j.icheatmasstransfer.2013.02.014

[10] Z. Said, R. Saidur, A. Hepbasli, N.A. Rahim, New thermophysical properties of water based TiO2 nanofluid—the hysteresis phenomenon revisited, Int. Commun. Heat Mass Transf. 58 (2014) 85–95.

DOI: 10.1016/j.icheatmasstransfer.2014.08.034

[11] E. Zarifi, G. Jahanfarnia, Subchannel analysis of TiO2 nanofluid as the coolant in VVER-1000 reactor. Prog. Nucl. Energy 73 (2014) 140–152.

DOI: 10.1016/j.pnucene.2014.02.004

[12] H.M. Ali, H. Ali, H. Liaquat, H.T.B. Maqsood, M.A. Nadir, Experimental investigation of convective heat transfer augmentation for car radiator using ZnO–water nanofluids, Energy 84 (2015) 317–324.

DOI: 10.1016/j.energy.2015.02.103

[13] M. Sheikholeslami, Numerical modeling of nano enhanced PCM solidification in an enclosure with metallic fin, J. Mol. Liq. 259 (2018) 424-438.

DOI: 10.1016/j.molliq.2018.03.006

[14] T.A. Alkanhal, M. Sheikholeslami, M. Usman, R.U. Haq, A.S. Al-Ahmadi, I. Tlili, Thermal management of MHD nanofluid within the porous medium enclosed in a wavy shaped cavity with square obstacle in the presence of radiation heat source, Int. J. Heat Mass Transf. 139 (2019) 87–94.

DOI: 10.1016/j.ijheatmasstransfer.2019.05.006

[15] M.A. Nazari, M.H. Ahmadi, M. Sadeghzadeh, et al., A review on application of nanofluid in various types of heat pipes, J. Cent. South Univ. 26 (2019) 1021–1041.

DOI: 10.1007/s11771-019-4068-9

[16] A.C.V. Ramudu, K.A. Kumar, V. Sugunamma, N. Sandeep, Heat and mass transfer in MHD Casson nanofluid flow past a stretching sheet with thermophoresis and Brownian motion, Heat Transfer (2020) 1– 18. https://doi.org/10.1002/htj.21865.

DOI: 10.1002/htj.21865

[17] W. Yu, D. M. France, E.V. Timofeeva, D. Singh, J.L. Routbort, Thermophysical property-related comparison criteria for nanofluid heat transfer enhancement in turbulent flow, Appl. Phys. Lett. 96 (2010) 213109.

DOI: 10.1063/1.3435487

[18] W. Yu, D.M. France, E.V. Timofeeva, D. Singh, J.L. Routbort, Comparative Review of Turbulent Heat Transfer of Nanofluids, Int. J. Heat Mass Transfer 55 (2012) 5380–5396.

DOI: 10.1016/j.ijheatmasstransfer.2012.06.034

[19] K.A. Kumar, V. Sugunamma, N. Sandeep, M.T. Mustafa, Simultaneous solutions for first order and second order slips on micropolar fluid flow across a convective surface in the presence of Lorentz force and variable heat source/sink, Sci. Rep. 9 (2019) 14706.

DOI: 10.1038/s41598-019-51242-5

[20] B. Ramadevi, K.A. Kumar, V. Sugunamma, N. Sandeep, Influence of non-uniform heat source/sink on the three-dimensional magnetohydrodynamic Carreau fluid flow past a stretching surface with modified Fourier's law, Pramana – J. Phys. 93 (2019) 86.

DOI: 10.1007/s12043-019-1847-7

[21] I.E. Mouromtseff, Water and forced-air cooling of vacuum tubes, Proceedings of the IRE 30 (1942) 190–205.

DOI: 10.1109/jrproc.1942.234654

[22] M.V. Bozorg, M.H. Doranehgard, K. Hong, Q. Xiong, CFD study of heat transfer and fluid flow in a parabolic trough solar receiver with internal annular porous structure and synthetic oil–Al2O3 nanofluid, Renew. Energ. 145 (2020) 2598-2614.

DOI: 10.1016/j.renene.2019.08.042

[23] H.M. Ali, In tube convection heat transfer enhancement: SiO2 aqua based nanofluids, J. Mol. Liq. 308 (2020) 113031.

DOI: 10.1016/j.molliq.2020.113031

[24] A. Bibi, H. Xu, Peristaltic channel flow and heat transfer of Carreau magneto hybrid nanofluid in the presence of homogeneous/heterogeneous reactions, Sci. Rep. 10 (2020) 11499.

DOI: 10.1038/s41598-020-68409-0

[25] I. Tlili, M.T. Mustafa, A.K. Kumar, N. Sandeep, Effect of asymmetrical heat rise/fall on the film flow of magnetohydrodynamic hybrid ferrofluid, Sci. Rep. 10 (2020) 6677.

DOI: 10.1038/s41598-020-63708-y

[26] E.C. Okonkwo, I. Wole-Osho, I.W. Almanassra, Y.M. Abdullatif, T. Al-Ansari, An updated review of nanofluids in various heat transfer devices. J. Therm. Anal. Calorim. (2020). https://doi.org/10.1007/s10973-020-09760-2.

DOI: 10.1007/s10973-020-09760-2

[27] J.A. Eastman, S.U.S. Choi, S. Li, G. Soyez, L.J. Thompson, R.J. DiMelfi, Novel thermal properties of nanostructured materials, Material Science Forum 312-314 (1999) 629–634.

DOI: 10.4028/www.scientific.net/msf.312-314.629

[28] Y. Xuan, W. Roetzel, Conceptions for heat transfer correlations of nanofluids, Int. J. Heat Mass Transfer 43 (2000) 3701–3707.

DOI: 10.1016/s0017-9310(99)00369-5

[29] I. Ishihara, T. Fukui, R. Matsumoto, Natural convection in a vertical rectangular enclosure with symmetrically localized heating and cooling zones, Int. J. Heat Fluid Flow 23 (2002) 366-372.

DOI: 10.1016/s0142-727x(02)00184-4

[30] J. Buongiorno, Convective Transport in Nanofluids, J. Heat Transfer 128 (2006) 240–250.

DOI: 10.1115/1.2150834

[31] R.L. Hamilton, O.K. Crosser, Thermal Conductivity of Heterogeneous Two-Component System, I and EC Fund. 1 (1962) 187–191.

[32] X. Zhang, H.M. Fujii, Effective Thermal Conductivity and Thermal Diffusivity of Nanofluids Containing Spherical and Cylindrical Nanoparticles, J. Appl. Phys. 100 (2006) 044325.

DOI: 10.1063/1.2259789

[33] J.C. Maxwell-Garnett, Colours in metal glasses and in metallic films, Philos. Trans. Roy. Soc. A 203 (1904) 385-420.

[34] F.J. Wasp, Solid-liquid slurry pipeline transportation, Berlin, Trans Tech, (1977).

[35] H.C. Brinkman, The viscosity of concentrated suspensions and solutions, J. Chem. Phys. 20 (1952) 571–581.

[36] E.B. Öğüt, Natural convection of water-based nanofluids in an inclined enclosure with a heat source, International Int. J. Therm. Sci. 48 (2009) 2063-2073.

DOI: 10.1016/j.ijthermalsci.2009.03.014

[37] S. Ferrouillat, A. Bontemps, J.P. Ribeiro, J.A. Gruss, O. Soriano, Hydraulic and heat transfer study of SiO2/water nanofluids in horizontal tubes with imposed wall temperature boundary conditions, Int. J. Heat Fluid Flow 32 (2011) 424–439.

DOI: 10.1016/j.ijheatfluidflow.2011.01.003

[38] J. Sarkar, A Critical Review on Convective Heat Transfer Correlations of Nanofluids, Renew. Sustain. Energy Rev. 15 (2011) 3271–3277.

DOI: 10.1016/j.rser.2011.04.025

[39] A.H.A. Al-Waeli, K. Sopian, M.T. Chaichan, H.A. Kazem, H.A. Hasan, A.N. Al-Shamani, An experimental investigation of SiC nanofluid as a base-fluid for a photovoltaic thermal PV/T system, Energ. Convers. Manage. 142 (2017) 547-558.

DOI: 10.1016/j.enconman.2017.03.076

[40] H.F. Oztop, E. Abu-Nada, Numerical study of natural convection in partially heated rectangular enclosures filled with nanofluids, Int. J. Heat Fluid Flow, 29 (2008) 1326-1336.

DOI: 10.1016/j.ijheatfluidflow.2008.04.009

[41] A.E. Bergles, Evolution of Cooling Technology for Electrical, Electronic, and Microelectronic Equipment IEEE T. Compon. Pack. T. 26 (2003) 6-15.

[42] R.E. Simons, Comparing Heat Transfer Rates of Liquid Coolants Using the Mouromtseff Number, Electronic Cool. 12 (2006).

[43] H. Etherington, (Ed) Nuclear Engineering Handbook New York, USA, McGraw-Hill Book Company, Inc., (1958).

[44] R.S. Vajjha, D.K. Das, A Review and Analysis on Influence of Temperature and Concentration of Nanofluids on Thermophysical Properties, Heat Transfer and Pumping Power, Int. J. Heat Mass Transfer, 55 (2012) 4063–4078.

DOI: 10.1016/j.ijheatmasstransfer.2012.03.048

[45] W. Yu, D.M. France, E.V. Timofeeva, D. Singh, J.L. Routbort, Thermophysical property-related comparison criteria for nanofluid heat transfer enhancement in turbulent flow, Appl. Phys. Lett. 96 (2010) 213109.

DOI: 10.1063/1.3435487

[46] M.N. Pantzali, A.G. Kanaris, K.D. Antoniadis, A.A. Mouza, S.V. Paras, Effect of nanofluids on the performance of a miniature plate heat exchanger with modulated surface, Int. J. Heat Fluid Flow 30 (2009) 691–699.

DOI: 10.1016/j.ijheatfluidflow.2009.02.005

[47] D. Zhong, H. Zhong, T. Wen, Investigation on the thermal properties, heat transfer and flow performance of a highly self-dispersion TiO2 nanofluid in a multiport mini channel, Int. Commun. Heat Mass 117 (2020) 104783.

DOI: 10.1016/j.icheatmasstransfer.2020.104783

[48] D. Senthilkumar, S. Wongwises, Enhancing thermal conductivity of water by using TiC nanopowder with cryogenic treatment, Mater. Res. Innov. 24 (2020) 145-151.

DOI: 10.1080/14328917.2019.1619260

[49] L. Yang, K. Du, Z. Zhang, Heat transfer and flow optimization of a novel sinusoidal minitube filled with non-Newtonian SiC/EG-water nanofluids, Int. J. Mech. Sci. 168 (2020) 105310.

DOI: 10.1016/j.ijmecsci.2019.105310

[50] L. Yang, K. Du, A comprehensive review on the natural, forced, and mixed convection of non-Newtonian fluids (nanofluids) inside different cavities. J. Therm. Anal. Calorim. 140 (2020) 2033–(2054).

DOI: 10.1007/s10973-019-08987-y

[51] F. Pourfayaz, N. Sanjarian, A. Kasaeian, et al., An experimental comparison of SiO2/water nanofluid heat transfer in square and circular cross-sectional channels, J. Therm. Anal. Calorim. 131 (2018) 1577–1586.

DOI: 10.1007/s10973-017-6500-4
