Mechanism of EDM Intensification at Ultrasound Application

Abstract:

This paper considers some theoretical provisions on the impact ultrasonic mechanical vibrations have on the throughput of an electroerosive piercing of small-diameter holes. The approximate estimates confirm the hypothesis that the cumulative jets mechanism makes the greatest contribution to the intensification of a multiphase medium flow in the interelectrode gap. A model is proposed for a periodic localization of the cavitation region in the bottom part of the annular side gap. It allows explaining the occurrence of a multiphase medium flow during hole processing.

• Periodical: Defect and Diffusion Forum (Volume 410)
• Pages: 21-27
• DOI: https://doi.org/10.4028/www.scientific.net/DDF.410.21
• Online since: August 2021
• Authors: Andrey A. Gruzdev, Yuriy A. Morgunov*, Boris P. Saushkin
• Keywords: Electroerosive Piercing of Holes, Mechanism of Erosion Products Evacuation, Small-Diameter Holes, Ultrasound Exposure
