Heat Transfer and Fluid Flow in Concentric Annular Ducts Using the Galerkin-Based Integral Method: A Numerical Study

Abstract:

In this paper, we cope with the problem of presents a numerical analysis for heat transfer in a duct with geometry circular annular elliptical using the Galerkin-based integral method. The analysis is performed for different geometries of the duct (circular annular circular and circular annular elliptical), and the method is validated for circular cylindrical geometry. Parameters such as mean temperature and mean and location Nusselt numbers for two boundary conditions: constant wall temperature and axial constant heat flux in the wall with constant wall temperature are presented and analyzed.

• Periodical: Diffusion Foundations and Materials Applications (Volume 30)
• Pages: 53-68
• DOI: https://doi.org/10.4028/p-oxd8cb
• Online since: August 2022
• Authors: Valdecir A.S. Júnior*, Severino Rodrigues Farias Neto, Antonio Gilson Barbosa de Lima
• Keywords: Annular Ducts, Fluid Flow, GBI Method, Heat Transfer, Simulation
