Comparative Quantum Analysis of Si/Ge Channel Tri-Gate Mosfets

Abstract:

In this article we have developed an analytical model for Tri-gate Metal Oxide Semiconductor Field Effect Transistor (TG MOSFET) including Quantum effects for High-k/Ge material. The Schrodinger–Poisson’s equation is used to develop the analytical Quantum model using Variational method. A mathematical expression for charge centroid is obtained and then an inversion charge model was developed with quantum effects by means of oxide capacitance for different channel thickness and gate oxide thickness. The compact model is shown to reproduce transfer characteristics, transconductance and C-V curves of Tri-gate MOSFETs using the model and is compared with the device for Si/SiO₂ material. The results of both the model are compared to the simulated results. The comparison shows the accuracy of the proposed model for the high-k and Ge material.

• Periodical: Journal of Nano Research (Volume 58)
• Pages: 32-39
• DOI: https://doi.org/10.4028/www.scientific.net/JNanoR.58.32
• Online since: June 2019
• Authors: P. Vimala*, N.R. Nithin Kumar
• Keywords: Inversion Charge, Inversion Charge Density, Inversion Layer Centroid, Quantum Effect, Tri-Gate MOSFETs

References

[1] Andreas Tsormpatzoglou, Charalabos A. Dimitriadis,Raphael Clerc, G. Pananakakis, and Gerard Ghibaudo, Semi analytical Modeling of Short-Channel Effects in Lightly Doped Silicon Trigate MOSFETs,, IEEE TRANSACTIONS ON ELECTRON DEVICES, VOL. 55, NO. 10, OCTOBER 2008,pp- 2623-2631.

DOI: 10.1109/ted.2008.2003096

[2] Subhradip Das and Sudakshina Kundu, Simulation to Study the Effect of Oxide Thickness and High-K Dielectric on Drain-Induced Barrier Lowering in N-type MOSFET,IEEE TRANSACTIONS ON NANOTECHNOLOGY, VOL. 12, NO. 6, NOVEMBER,2013, pp.945-947.

DOI: 10.1109/tnano.2013.2276441

[3] Sang-Hyeon Kim, Masafumi Yokoyama, RyoshoNakane, Osamu Ichikawa, TakenoriOsada, Masahiko Hata, Mitsuru Takenaka, and Shinichi Takagi, High Performance Tri-Gate Extremely Thin-Body InAs-On-Insulator MOSFETs With High Short Channel Effect Immunity and Vth Tunability,, IEEE TRANSACTIONS ON ELECTRON DEVICES, VOL. 61, NO. 5, MAY 2014, pp-1354 1360.

DOI: 10.1109/ted.2014.2312546

[4] Vimala P, Charge Based Quantization Model for Triple-Gate FINFETS,, JOURNAL OF NANO- & ELECTRONIC PHYSICS. 2018, Vol. 10 Issue 5, pp.1-5. 5p.

[5] P. Vimala & N.B. Balamurugan,Modelling the centroid and charge density in double-gate MOSFETs including quantum effects,, INTERNATIONAL JOURNAL OF ELECTRONICS, Vol.100, No.9,2013,pp-1283-1295.

DOI: 10.1080/00207217.2012.743081

[6] Cong Li, Yiqi Zhuang and Li Zhang, Simulation study on FinFET with tri-material gate,, School of Microelectron.

[7] Bin Yu, Leland Chang, Shibly Ahmed, Haihong Wang, Scott Bell, Chih-Yuh Yang, Cyrus Tabery, Chau Ho, Qi Xiang, Tsu-Jae King, Jeffrey Bokor, Chenming Hu, Ming-Ren Lin, and David Kyser, FinFET Scaling to 10nm Gate Length,, Strategic Technology, Advanced Micro Devices, Inc., Sunnyvale, CA 94088, USA (2002).

DOI: 10.1109/iedm.2002.1175825

[8] SurajitBera, Chandrima Mondal1, Abhijit Biswas, Development of a methodology for the extraction of BSIM parameters of Ge‑channel MOSFETs and estimation of analog circuit performance,, MicrosystTechnol,Springer (2017).
