Damping Ratio Estimation of Linear and Non-Linear Viscoelastic Materials Using Hilbert and Wavelet Analysis Techniques

Abstract:

The damping property is a material's energy dissipation capacity, indicating its ability to resist vibrations. The parameters of damping characteristics can be evaluated using the traditional Fast Fourier Transformation (FFT) technique, which suffers from the loss of time. Therefore, Hilbert Transform (HT) and Wavelet Transform (WT) have been developed to overcome such problems and help comprehend damping properties precisely with time and frequency. This study evaluates and compares damping ratio assessment using HT, WT, and Log Decrement in linear and non-linear viscoelastic material models. To test the adapted HT and WT methods, we developed a homemade MATLAB code to evaluate the damping ratio of two data sets. Analytical data obtained from solving a linear viscoelastic material model and numerical data attained from the FE-model of a non-linear viscoelastic material were both subjected to vibration. The error percentages of the damping ratio estimated by HT and WT were 6.1 and 11.75, respectively, compared to 43 for Log Decrement. These results confirm that HT and WT can accurately predict the damping ratio of non-linear viscoelastic material models.

• Periodical: Key Engineering Materials (Volume 1016)
• Pages: 121-126
• DOI: https://doi.org/10.4028/p-8hqBqM
• Online since: June 2025
• Authors: Awad Megahed*, Ahmed M.R. Fath El-Bab, Haitham Elhussieny, Mohsen A. Hassan
• Keywords: Damping Ratio, Hilbert Transform, Viscoelasticity, Wavelet Transform

References

[1] Hernández-Flores, E. A., Hernández-Rodríguez, Y.M., Munguía-Fuentes, R., Bayareh-Mancilla, R., & Cigarroa-Mayorga, O.E. (2024). Acinonyx jubatus-Inspired Quadruped Robotics: Integrating Neural Oscillators for Enhanced Locomotion Control. Biomimetics, 9(6), 318.

DOI: 10.3390/biomimetics9060318

[2] Macioce, P. (2003). Viscoelastic damping 101. Sound and Vibration, 1, 10-12.

[3] Sumali, H., & Kellogg, R. A. (2011). Calculating Damping from Ring-Down Using Hilbert Transform and Curve Fitting (No. SAND2011-1960C). Sandia National Lab.(SNL-NM), Albuquerque, NM (United States).

DOI: 10.2172/1033330

[4] Feldman, M. (1997). Non-linear free vibration identification via the Hilbert transform. Journal of Sound and Vibration, 208(3), 475-489.

DOI: 10.1006/jsvi.1997.1182

[5] Ruzzene, M., Fasana, A., Garibaldi, L., & Piombo, B. (1997). Natural frequencies and dampings identification using wavelet transform: application to real data. Mechanical systems and signal processing, 11(2), 207-218.

DOI: 10.1006/mssp.1996.0078

[6] Lardies, J., & Gouttebroze, S. (2002). Identification of modal parameters using the wavelet transform. International Journal of Mechanical Sciences, 44(11), 2263-2283.

DOI: 10.1016/s0020-7403(02)00175-3

[7] Ahmadi, M. W., Hill, T. L., Jiang, J. Z., & Neild, S. A. (2023). Reduced-order model-inspired system identification of geometrically non-linear structures: application to a non-linear cantilever type structure. Non-linear Dynamics, 111(19), 17887-17907.

DOI: 10.1007/s11071-023-08813-z
