Growth of Highly Luminescent Silicon Nanocrystals by Rapid Thermal Chemical Vapor Deposition

Abstract:

We investigate the growth of highly luminescent silicon nanocrystals by rapid thermal chemical vapor deposition (RTCVD), employing SiH4 and N2O as source gases. For [N2O]/[SiH4] = 7 ∼ 8 and a growth temperature of 650°C, we obtain the optimized deposition condition for silicon rich oxide (SRO) layer having highly luminescent Si nanocrystals after post-deposition annealing. The cross sectional transmission electron microscope investigation reveals the existence of Si nanocrystals in the SRO matrix. Thus, the photoluminescence (PL) from the SRO layer is attributed to the quantum confinement effect of carriers in Si nanocrystals. Based on a single layer growth study, we fabricate ultra-thin SRO/SiO2 superlattice having 25 periods on a 3-inch Si wafer. The superlattice has continuous thickness variation from the center to the edge positions of the Si wafer due to inherent wafer temperature variation during growth. Photoluminescence spectra show a systematic blue-shift from a thicker position (center position) to a thinner position (edge position) which is indicative of nanocrystal size control by SRO layer thickness in the superlattice.

• Periodical: Key Engineering Materials (Volumes 277-279)
• Pages: 977-982
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.277-279.977
• Online since: January 2005
• Authors: Hea Jeong Cheong, Jung Hyun Kang, Jae Kwon Kim, Kim Yong
• Keywords: Nanocrystal, Photoluminescence (PL), Rapid Thermal Chemical Vapor Deposition, Silicon, TEM

References

[1] L. T. Canham., Appl. Phys. Lett. Vol. 57 (1990), p.1046.

[2] K. S. Min: Synthesis and properties of light-emitting Si-based nanostructures (Ph. D. thesis, Caltech, 2000).

[3] F. Iacona, G. Franzo, and C. Spinella, J. Appl. Phys. Vol. 87 (2000), p.1295.

[4] S. Lombardo, S. U. Campisano, Mat. Sci. Eng. Vol. R17 (1996), p.281.

[5] S. Lombardo, S. Coffa, C. Bongiorno, C. Spinella, E. Castagna, A. Sciuto, C. Gerardi, F. Ferrari, B. Fazio, and S. Privitera, Mat. Sci. Eng. Vol. B69-70 (2000), p.295.

DOI: 10.1016/s0921-5107(99)00290-1

[6] P. Bruesch, Th. Stockmeier, F. Stucki and P. A. Buffat, J. Appl. Phys. Vol. 73 (1993), p.7677.

[7] M. Zacharias, J. Heitmann, R. Scholz, U. Kahler, M. Schmidt, and J. Blasing, Appl. Phys. Lett. Vol. 80 (2002), p.661.

[8] M. Fujii, S. Hayashi, and K. Yamamoto, Jpn. J. Appl. Phys. Vol. 30 (1991), p.687.

[9] L. Patrone, D. Nelson, V. I. Safarov, M. Sentis, W. Marine and S. Giorgio, J. Appl. Phys. Vol. 87 (2000) p.3829.

[10] C. Y. Chang and S. M. Sze: ULSI technology, chap. 4 (McGraw-Hill, New York 1996).

[11] J. F. Gibbons, C. M. Gronet, and K. E. Williams, Appl. Phys. Lett. Vol. 47 (1986), p.721.

[12] X. L. Xu, R. T. Kuehn, J. J. Wortman, and M. C. Ozturk, Appl. Physic. Lett. Vol. 60 (1992), p.3063.

[13] H. J. Cheong, J. H. Kang, J. K. Kim, Yong Kim, J-Y. Yi, T. H. Chung, and H. J. Bark, Appl. Phys. Lett. Vol. 83 (2003), p.2922.

[14] U. Kahler and H. Hofmeister, Appl. Phys. A Vol. 74 (2002), p.13.

[15] M. Zacharias and P. Streitenberger, Phys. Rev. B Vol. 62 (2000), p.8391.

[16] M. Zacharias, J. Heitmann, R. Scholz, U. Kahler, M. Schmidt and J. Blasing, Appl. Phys. Lett. Vol. 80 (2002), p.661. Title of Publication (to be inserted by the publisher).

[17] B. Garrido Fernandez, M. Lopez, C. Garcia, A. Perez-Rodriguez, J. R. Morante, C. Bonafas, M. Carrada, and A. Claverie, J. Appl. Phys. Vol. 91 (2002), p.798.

[18] G. Lucovsky, M. J. Manitini, J. K. Stivastava, and E. A. Irene, J. Vac. Sci. Technol. B Vol. 5 (1987), p.530.

[19] P. G. Pai, S. S. Chao, Y. Takagi, and G. Lucovsky, J. Vac. Sci. Technol. A Vol. 4 (1986), p.689.

[20] X. Ren, M. C. Ozturk, J. J. Wortman, B. Zhang, D. M. Maher, and D. Batchelor, J. Vac. Sci. Technol. B Vol. 10 (1992), p.1081.
