A Plastic Film Thickness On-Line Detecting System

Abstract:

In this paper, the main new point is the use of a non-contact combinational system with a capacitive sensor and eddy current sensors to acquire measurement signals and the use of LabVIEW software platform for real time data processing of plastic film thickness. Using a combinational measurement system to replace a traditional micrometer, the thickness of plastic film can be measured intelligently, real time, and in non-contact mode with high precision. The whole system consists of a test unit, a data acquisition unit, a motor driving unit, and a data processing unit. The test unit does measurement by means of capacitive sensor and eddy current sensors. The system is operated on the LabVIEW software platform for automatic control of the whole process. The measurement process is faster. The test results from the combinational measurement system are compared with the results from a micrometer. It shows that this measurement system has higher precision and better repeatability, reliability and feasibility.

• Periodical: Key Engineering Materials (Volumes 295-296)
• Pages: 387-392
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.295-296.387
• Online since: October 2005
• Authors: Yu Zhen Ma, S.H. Ye, F. Duan, Y. Zheng
• Keywords: Combinational Measurement, On-Line, Plastic Film, Thickness

References

[1] Q. Chen: China Plastics, Vol. 15 (2001), p.62.

[2] Y. Zheng: The Principle and Application of Capacitive Sensors (Tianjin University Publications, Tianjin 1986).

[3] X. Qiang: Sensors (Mechanical Industries Publications, Beijing 1994).

[4] X. Zhang, G. Hou and W. Zhao: Measurement & Control Technology, Vol. 19 (2000), p.22.

[5] X. Song, D. Liu and Y. Guo: Measurement Technique, 2001, p.15.

[6] L. Yang: Labview Program Design and Application (Electronic Industries Publications, Peking 2001).

[7] L. Chen: Step Motor and Application (Science & Technology Publications, Shanghai 1985).

[8] Y. Yu: Computer Interface Technique (Electronic Industries Publications, Beijing 1996). Position of sampling points 21 22 23 24 25 20 26 11 4 6 18 17 19 16 15 14 13 12 10 9 8 1 2 3 5 7 20 No. Micrometer Torsion spring micro-measuring apparatus Combinational system.
