Instantaneous Measurement of 3D Profiles by Projecting Coded Grating

Abstract:

A three-dimensional profile measurement system based on a projection coded grating technique is presented. The system uses a designing and decoding technique for grey coded gratings. The coded grating has black, white and grey stripes. The period triples a conventional grating. It greatly increases the height measuring range without any decrease in stripe separation. The shape of object can be obtained from only one grating image. The system is suitable for instantaneous measurement of moving objects including human face. The technique proposed permits rapid 3D measurement and no moving parts are involved in the system. The hardware is relatively simple. Special data processing software is developed. Results of a practical example confirm the effectiveness of the proposed method.

• Periodical: Key Engineering Materials (Volumes 295-296)
• Pages: 495-500
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.295-296.495
• Online since: October 2005
• Authors: A.L. Tian, B. Li, M.T. Huang, Zhuang De Jiang
• Keywords: Decode Processing, Digital Fringe Projection, Grey Code Grating, Instantaneous Measurement, Three-Dimension Profile

References

[1] M. Takeda and K. Mutoh: Applied Optics, Vol. 22 (1983), p.3977.

[2] A. Asundi: Optical Engineering, Vol. 32 (1993), p.213.

[3] G. Sansoni, L. Biancardi, U. Minoni and F. Docchio: IEEE Transactions Instrument Measurement, Vol. 43 (1993), p.548.

[4] S. Tang and Y.Y. Hung: Applied Optics, Vol. 29 (1990), p.3012.

[5] M. Halioua, R.S. Krishnamurthy, H. Liu and F.P. Chiang: Applied Optics, Vol. 22 (1983), p.850.

[6] P.S. Huang, Q. Hu, F. Jin and F.P. Chiang: Optical Engineering, Vol. 38 (1999), p.1065.

[7] W.S. Zhou and X.Y. Su: Modern Optics, Vol. 41 (1994), p.561.

[8] C.R. Coggrave and J.M. Uuntly: Optical Engineering, Vol. 39 (2000), p.91.

[9] T.R. Judge and P.J. Bryanston-Cross: Optical Lasers Engineering, Vol. 21 (1994), p.199.

[10] A. Asundi, C.S. Chan and M.R. Sajan: Optical Engineering, Vol. 33 (1994), p.2760.

[11] J.P. Kruth and A.K. Erstens: Journal of Materials Processing Technology, Vol. 76 (1998), p.120.

[12] A. Alrashdan, S. Motavalli and B. Fallahi: IIE Transactions, Vol. 32 (2000), p.59.

DOI: 10.1023/a:1007655430826

[13] Z. Wang, Y.S. Tan and H. Zhao: Laser & Infrared, Vol. 29 (1999), p.99.

[14] W.Y. Liu, Z.Q. Wang, G.G. Mu and Z.L. Fang: Acta Optica Sinica, Vol. 9 (2000), p.1218.

[15] S.D. Zhang and Q. Fang: Journal of Optics, Vol. 36 (1997), p.1533.

[16] Q.Q. Ruan: Digital Image Process (Publishing Company of Electric Industry, Beijing 2001).
