Research on Microstructures of Alloyed Layer by Plasma Surface Alloying with Tungsten and Molybdenum

Abstract:

The alloying elements W-Mo cementation is carried out on the surfaces of low carbon steels by the technique of plasma metallurgy. Then by using the plasma-supersaturated carbonization, the composition of surface alloying layer reaches or approaches that of low-alloy HSS. In the end the surface alloying layer possesses high hardness, favorable red hardness and a significant improvement in properties after high temperature quenching and high temperature tempering. The surface cementation structure and phase structure of alloying layer were analyzed using metallographic microscope and X-ray diffraction (XRD), respectively; the distribution of surface composition and hardness of the layer were investigated by Glow Discharge Analytical Instrument (GDA) and micro hardness instrument, respectively; the resistance to wear was tested by a abrasion machine. The experimental results indicated that the layer consisted of W-Mo solid solution in Fe, the depth of the layer could reach 100µm and the content of tungsten exceeded 10% after ion W-Mo cementation. The carbon content of carburized layer was 1.3% above, which was composed of M6C carbide containing a lot of elements of W-Mo. The surface hardness of the alloying layer attained the HV1000 or so and appeared graded distribution after quenching and tempering. The application study showed that alloying elements W-Mo cementation was an appropriate technique to enhance surface resistance to wear and prolong operating life of accessories.

• Periodical: Key Engineering Materials (Volumes 297-300)
• Pages: 1108-1112
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.297-300.1108
• Online since: November 2005
• Authors: Gao Yuan, Jin Yong Xu, Yan Ping Liu, Jian Zhong Wang, Xiaoyun Kui, Zhong Xu
• Keywords: Carbide, Diffusion Layer, Low-Alloy HSS, Plasma, Surface Alloying

References

[1] Deng Yukun, Chen Jingrong and Wang Shizhang compilation: High Speed Tool Steels (Beijing, Machine Industry Press, 2002), p.16.

[2] Liu Zhanqiang: Recent Development in HSS Tools (Tools Technique, 2001, 3), pp.3-7.

[3] Luo Di: An Introduction of High Speed Tool Steels in Recent Development (Special Steel, 1996, 2), pp.8-12.

[4] Gao Yuan: Research on Surface Low-alloy HSS by Plasma Surface Metallurgy W、Mo、C Alloying Process (Taiyuan University of Technology Doctor Paper, 2003, 12).

[5] Zhou Kaiyi compilation: Hollow Cathode Discharge and its Application (Vacuum Science and Technique, Beijing 1982), pp.7-8.

[6] Chen Dakai compilation: Plasma Chemical Heat Treatment (Machine Industry Press, Beijing 1990), p.67.

[7] Guo Gengsan compilation: HSS and its Heat Treatment (Machine Industry Press, Beijing 1985), p.93.

[8] Gao Yuan: A Study of Ion Cementation Alloying Elements on W-Mo hacksaw blade and Sawability (Weapon Industry Bulletin, 1998, 4), p.45.

[9] Gao Yuan: The Application and Research of the Improving Wear Resistance of the Stainless Steel Colloid Mill by Double Glow Plasma Alloying Technique (Shanxi Province Science and Technology Committee Expertise Report [2004. 034], 2004, 4, 25).

[10] Xu Zhong: US Patent 4520286 and 4731539, UK Patent 2150602, Japan Patent 1872305.

[11] Gao Yuan: Microstructure Analysis of 20CrV Steel after Carbonization by SEM (Electron Microscopy Bulletin, 1999, 7), p.56.

[12] Gao Yuan: Plasma Surface Alloying HSS Power Hacksaw Blades (Tools Technique, 2002), p.42.
