Study on Block Electrode Discharge Grinding of Micro Rods

Abstract:

Block electrode discharge grinding is an effective approach to produce micro rods. However, it is difficult to fabricate the rods into desired miniature and precision. To solve this problem, the tangential feeding method is proposed to control the finish size of micro rods. With this method, the micro rod is first fed in its radial direction, and then in the tangential direction for an enough distance. The wear of the block electrode decreases gradually from the start to the end, and the wear in the end can be neglected. Experiments indicate that the large capacitance or voltage can obtain high machining speed, while the small ones can gain thin micro rods. Based on this result, the policy of delaminating grinding is adopted to gain enough thin micro rods at a high machining speed. The Φ5µm micro rods can be ground with this method. SEM results show that the relative error of the size control is less than 10%.

You might also be interested in these eBooks

Advances in Grinding and Abrasive Technology XIII

View Preview

Info:

Periodical:

Key Engineering Materials (Volumes 304-305)

Pages:

201-205

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.304-305.201

Citation:

Cite this paper

Online since:

February 2006

Authors:

Wan Sheng Zhao, B.X. Jia, Zhen Long Wang, Fu Qiang Hu

Keywords:

Block Electrode, Electro Discharge Machining (EDM), Grinding, Micro Machining, Micro Rod, Precision

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Z.Y. Yu, T. Masuzawa and M. Fujino: Int. J. Electr. Machining, Vol. 3 (1998), p.7.

Google Scholar

[2] K.P. Rajurkar and Z.Y. Yu: Ann. CIRP, Vol. 49 (2000), p.127.

Google Scholar

[3] N. Mohri, H. Takezawa, K. Furutani, Y. Ito and T. Sata: Ann. CIRP, Vol. 49 (2000), p.123.

Google Scholar

[4] W. S. Zhao, Z. L. Wang and S. C. Di: J. Mater. Proc. Tech, Vol. 120 (2002), p.101.

Google Scholar

[5] T. Masuzawa, M. Fujino and K. Kobayashi: Ann. CIRP, Vol. 34 (1985) No. 1, p.431.

Google Scholar

[6] N. Ravi and S. X. Chuan: J. Micromech. Microeng, Vol. 12 (2002), p.532.

Google Scholar

[7] B.X. Jia, Z.L. Wang, F.Q. Hu and W.S. Zhao: Mater. Sci. Forum, Vols. 471-472 (2004), p.37. Fig. 6 SEM photographs of micro rod machined by the tangential feeding method.
