Quartz Wafer Machining Using MCF (Magnetic Compound Fluid) Polishing Liquid Frozen with Liquid Nitrogen

Abstract:

This paper deals with the machining of quartz wafers using an MCF (Magnetic Compound Fluid) polishing liquid, frozen with liquid nitrogen. This type of polishing liquid is composed of water-based MF (Magnetic Fluid), iron powder, abrasive particle and α-cellulose, and consequently reacting to magnetic fields. Experiments of polishing quartz wafers using the MCF method were carried out on a previously developed apparatus. The results show that an MCF polishing liquid, frozen with liquid nitrogen, has greater material removal capability than one that has not been frozen. A frozen MCF polishing liquid containing larger abrasive particles yields a higher material removal rate, however the surface roughness deteriorates. The highest material removal rate and the best surface roughness were obtained when the percentage of water, in the frozen MCF polishing tool, was 34.7%.

• Periodical: Key Engineering Materials (Volumes 389-390)
• Pages: 187-192
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.389-390.187
• Online since: September 2008
• Authors: Yong Bo Wu, Kunio Shimada
• Keywords: High Frequency Quartz Oscillator, Magnetic Compound Fluid (MCF), Material Removal, Polishing, Quartz Wafer, Surface Roughness (SR), Thickness

References

[1] I. Ida, etc.: J. JSPE, Vol. 25, No. 8 (1959), p.305 & No. 9 (1959), p.357.

[2] S. Sato: J. JSPE, Vol. 64, No. 1 (1998), p.71.

[3] A. Chiba, etc.: Proc. 1998 JSPE spring conference, (1998), p.569.

[4] M. Koyama, etc.: Proc. IEEE Int. Freq. Control Symp., Vol. 53, No. 1 (1999), p.338.

[5] Y. Nagaura, etc.: Proc. IEEE Int. Freq. Control Symp., Vol. 53, No. 1 (1999), p.425.

[6] S. Yokomizo, etc.: Machine technology (Kikai Gijutsu), Vol. 48, No. 8 (2000), p.33.

[7] T. Hagino, etc: J. JSPE, Vol. 66, No. 1 (2000), p.69.

[8] T. Kurobe, etc.: J. JSAT, Vol. 46, No. 5 (2002), p.250.

[9] K. Sawada, etc.: Latest progress on micro-fabrication research, Vol. 6, (2000), p.58.

[10] K. Nishihara, etc.: Proc. 2001 JSPE autumn conference, (2001), p.493.

[11] M. Ikeda, M, etc.: J. JSPE, Vlo. 66, No. 6 (2000), p.896.

[12] K. Yamamura, etc.: J. JSPE, Vol. 71, No. 4 (2005), p.455.

[13] M. Shibahara, etc.: J. JSPE, Vol. 72, No. 7 (2006), p.934.

[14] K. Tezuka, etc.: Proc. ABTEC2005, (2005), p.129.

[15] Y. Wu, etc.: Proc. Int. Con. on Precision Engineering and Micro/Nano Technology (ASPEN2005), Vol. 1, (2005), p.141.

[16] S. Kamiyama: Introduction of Magnetic Fluid (MF), Sangyo-tosho Inc., (1988), Tokyo.
