Enhanced Formability of Ultrafine-Grained Aluminum Blanks by Local Heat Treatments

Abstract:

High strength aluminum blanks can be obtained by grain-refinement due to an Accumulativ Roll Bonding (ARB) process, in which two sheets are iteratively brushed, stacked on top of each other and subsequently rolled together. The high shear stresses during the rolling cycles result in an ultrafine-grained microstructure with an average grain size ranging between 200 to 1000 nm. Whereas the grain-refinement causes a drastically increased strength of the aluminum material, the formability of the ARB-blanks made of industrially used aluminum alloys such as the AA6016 deteriorates to the same degree as the strength rises. In this context, a local heat treatment of the ARB-blank reducing the material’s strength and increasing its ductility in specific zones will allow to recover the blank’s formability again. The research work presented in this paper studies the microstructural effects of a short-term heat treatment on the mechanical properties of ARB-blanks made of AA6016. Experimental investigations including hardness measurements, tensile tests as well as microscopic analyses show that heat treatments of only several seconds already result in significant increases of the material’s ductility and decreases of the material’s strength. By applying these microstructural mechanisms in terms of a specific heat treatment layout, functional gradients of strength and ductility adapted to the succeeding forming operation can be setup significantly enhancing the ARB-blank’s formability.

• Periodical: Key Engineering Materials (Volumes 410-411)
• Pages: 169-176
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.410-411.169
• Online since: March 2009
• Authors: Marion Merklein, Uwe Vogt
• Keywords: AA6016, Formability, Local Heat Treatment, Ultrafine Grained Microstructure

References

[1] Mayr, E.: Mit Fusion öffnen wir die Tür für Aluminium noch weiter. In: Werkstoffe im Automobilbau, ATZ/MTZ-Extra Ausgabe, Vieweg Verlag / GWV Fachverlage GmbH Wiesbaden (2007), pp.26-28.

[2] Saito, Y.; Tsuji, N.; Utsunomiya, H.; Sakai, T.; Hong, R.G.: Ultra-Fine Grained Bulk Aluminum Produced by Accumulative Roll-Bonding (ARB) Process. In: Scripta Materialia, Vol. 39, No. 9 (1998), pp.1221-1227.

DOI: 10.1016/s1359-6462(98)00302-9

[3] Merklein, M.; Vogt, U.: Application of Tailored Heat Treated Blanks under quasi series conditions. Proceedings of the 12th International Conference on Sheet Metal (SheMet), Trans Tech Publications Ltd. (2007), pp.383-390.

[4] Merklein, M., Vogt, U.: Design Principles of Tailored Heat Treated Blanks for the manufacturing of complex car body parts. In: Nader Asnafi (Hrsg. ) : Proceedings of the IDDRG 2008 (2008), pp.557-569.

[5] Saito, Y.; Utsunomiya, H.; Tsuji, N.; Sakai, T.: Novel Ultra-High Straining Progress For Bulk Materials - Development of the Accumulative Roll-Bonding (ARB) Process. In: Acta Mater, Vol. 47, No. 2 (1999), pp.579-583.

DOI: 10.1016/s1359-6454(98)00365-6

[6] Topic, I.; Höppel, H. -W.; Göken, M.: Deformation behaviour, microstructure and processing of accumulative roll bonded aluminium alloy AA6016. In: International Journal of Material Research Vol. 98, No. 4 (2007), pp.320-324.

DOI: 10.3139/146.101469

[7] Hofmann, A.; Vollertsen, F.: Deep drawing of locally heat treated blanks. In: Geiger, M.; Vollertsen, F. (Hrsg. ): Laser Assisted Net Shape Engineering 2, Proceedings of the LANE'97 (1997), pp.719-732.

[8] Hogg, M.: Herstellung und Umformung lokal wärmebehandelter Platinen, PhD dissertation University of Stuttgart, DGM Informationsgesellschaft mgH, Frankfurt, (2006).
