Results of Nondestructive Inspection of Layered Composites Using IR Thermography and Ultrasonics

Abstract:

Polymeric layered composites exhibit a variety of damages following in service loading conditions, like delamination, matrix cracking or even fibre breaking. Detection of such damages and assessing their extension and severity is vital during maintenance cycle, in view of keeping the normal operational reliability. For local inspections, IR thermography and ultrasonic scanning are among the best valued NDT methods. The paper describes the inspections performed by IR active thermography, in different variants, and pulse-echo ultrasonic scanning on GFRP. A variety of layered composites and defects/damages were inspected and the results are evaluated independently, in some cases being compared each other, with valuable conclusions for the users of the mentioned NDI techniques.

• Periodical: Key Engineering Materials (Volumes 413-414)
• Pages: 343-350
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.413-414.343
• Online since: June 2009
• Authors: Nicolae Constantin, Alexandrina Mihai, Viorel Anghel, Mircea Găvan, Ştefan Sorohan, Wolfgang Hillger, Michael Sheerer
• Keywords: IRT, Nondestructive Inspection, Polymeric Composite, Ultrasonic Method

References

[1] T. S. Jones, in: Handbook of Composites, 2 nd edition, edited by S. T. Peters, （Chapman & Hall, London, New York 1998).

[2] Y. Bar-Cohen, A. S. Birks and F. H. Chang, in: &ondestructive Testing Handbook, 2nd edition, Vol. 10, S. Ness and Ch. N. Sherlock (tech. eds. ), P. O. Moore and P. McIntire (eds. ), section 11, ASNT (1996).

[3] R. J. Botsko and T. S. Jones, in: &ondestructive Testing Handbook, 2nd edition, Vol. 10, S. Ness and Ch. N. Sherlock (tech. eds. ) P. O. Moore and P. McIntire (eds. ), section 13, ASNT (1996).

[4] P. E. Mix: Introduction to &ondestructive Testing, a Training Guide, second edition, (John Wiley & Sons, Inc., Hoboker, NJ 2005).

[5] N. Constantin, V. Anghel, Şt. Sorohan, M. Găvan, D. Roşu and V. Turbatu: Proc. CEEX 2008 Conf. (2008), pp.240-1.

[6] C. Ibarra-Castanedo, D. Gonzales, M. Klein, M. Pilla, S. Vallerand and X. Maldague: Infrared Physics & Technology Vol. 46 (2004), p.75.

DOI: 10.1016/j.infrared.2004.03.011

[7] N. Constantin, W. Hillger, D. M. Constantinescu, M. Gǎvan, A. Mihai and C. Dumitraşcu: Proc. 21st DANUBIA-ADRIA Symp. on Exp. Methods in Solid Mech. (2004), p.18.

[8] N. Constantin, A. Mihai, M. Găvan, Şt. Sorohan, C. Dumitraşcu and V. Anghel: Key Eng. Mat. Vol. 347 (2007), p.615.

DOI: 10.4028/www.scientific.net/kem.347.615

[9] N. P. Avdelis, R. C. Hawtin and D. P. Almond: NDT&E Int., Vol. 36 (2003), p.433.
