Nanostructured Bionic PVD-Coatings for Forming Tools

Abstract:

It is very important to minimize wear and friction in forming processes in order to avoid adhesion between work piece and tool. For the realization of these requirements, the PVD-coating system CrAlN was deposited and tested on substrates made from high speed steel 1.3343 by means of a reactive sputter process. The coatings were deposited as single- and multilayers with a metallic Cr-interlayer. Prior to realizing the appropriate coating design, the substrates were pre-structured. For this purpose natural surfaces were used as a pattern and tested in this research work. The skin of an insect serves as a model and its fine structures were reproduced on the substrate surface by milling. The generated specimens were analyzed with a scanning electron microscope, nanoindenter and ball on disc tester to compare the performance of the coating systems.

• Periodical: Key Engineering Materials (Volume 438)
• Pages: 41-48
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.438.41
• Online since: May 2010
• Authors: Wolfgang Tillmann, Evelina Vogli, Jan Herper, Matthias Haase
• Keywords: Bionic Layer, CrAlN, Dung Beetle, Magnetron Sputtering, Multilayer

References

[1] F. -W. Bach: Moderne Beschichtungsverfahren, WILEY-VCH Verlag GmbH & Co. KGaA (2005).

[2] R. F. Bunshah and C. Weissmantel: Handbook of hard coatings, Noyes Publications/William Andrew Publishing (2001).

[3] K. Mertz and H.A. Jehn: Praxishandbuch moderne Beschichtungen, Carl Hanser Verlag GmbH & Co. KG (2001).

[4] M. Brizuela et al.: Surface & coatings technology Vol. 200 (2005), pp.192-197.

[5] H. C. Barshilia et al.: Surface & coatings technology Vol. 201 (2006), pp.2193-2201.

[6] X. Z. Ding et al.: Surface & coatings technology Vol. 200 (2005), pp.1372-1376.

[7] K. Bobzin et al.: Materialwissenschaft und Werkstofftechnik (2006) Vol. 37, No. 10 (2006), pp.833-841.

[8] J. Lin et al.: Surface & coatings technology (2006), Vol. 201, No. 7 (2006), pp.4329-4334.

[9] R. Wuhrer, W. Y. Yeung et al.: Scripta Materialia, Vol. 50 (2004), pp.1461-1466.

[10] H. Holleck et al.: Surface & coatings technology (1990), Vol. 41, pp.179-190.

[11] W. Tillmann et al.: Materials Science Forum, Vols. 539-543 (2) (2007), pp.1194-1199.

[12] W. Tillmann, E. Vogli et al.: 8. Werkstofftechnischen Kolloquium", (2005), pp.277-285.

[13] H. Zhou et al.: Materials science & engineering Vol. 412 (2005), pp.323-327.

[14] H. Zhou et al.: Materials science & engineering Vol. 417 (2006), pp.190-196.

[15] B. Chirende, J. Li et al.: Biotechnology and Molecular Biology Reviews Vol. 4 (2009), pp.42-48.

[16] W. Tillmann et al.: Steel Grips 7, Vol. 2009, pp.217-221.
