Simplified Calculation for Thermal Deformation of Scroll Wrap Height in a Small-Parameter Scroll Compressor

Abstract:

For the scroll wrap in small-parameter scroll compressor, its temperatures under stable operating condition are analyzed and the simulations for thermal deformation of scroll wrap height are performed. By fitting the simulations, a formula for simplified calculation of thermal deformation of scroll wrap height is proposed. The maximum deviations between simplified calculations for thermal deformation of orbiting scroll wrap height in a scroll compressor and simulations by FEM are no more than 5%, so the simplified calculation for thermal deformation of scroll wrap height is feasible. The experiment for the scroll compressor in which the orbiting scroll wrap is modified based on simplified calculation shows the modification for scroll wrap considering deformation of scroll wrap height can improve obviously the performances of scroll compressor. At the same time, reducing the temperature differences between the discharge and suction temperatures, limiting scroll wrap height, using the material having lower thermal expansion coefficient, and selecting a larger thickness of scroll wrap are other several effective means to reduce the influence of thermal deformation of scroll wrap height and to improve the performance of scroll compressor in engineering practice.

• Periodical: Key Engineering Materials (Volumes 467-469)
• Pages: 770-775
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.467-469.770
• Online since: February 2011
• Authors: Jian Guo Qiang
• Keywords: Calculation, Scroll Compressor, Thermal Deformation

References

[1] Chen Y, Halm N and Braun J: Mathematical modeling of scroll compressor-part I: compression process modeling. International Journal of Refrigeration Vol. 25(2002), p.731.

DOI: 10.1016/s0140-7007(01)00071-8

[2] Chen Y, Halm N and Braun J: Mathematical modeling of scroll compressor-part II: overall scroll compressor modeling. International Journal of Refrigeration Vol. 25(2002), p.751.

DOI: 10.1016/s0140-7007(01)00072-x

[3] Kitae Hang and Sangkwon Jeong: Experimental investigation on convective heat transfer mechanism in a scroll compressor. International Journal of Refrigeration Vol. 29(2006), P. 744.

DOI: 10.1016/j.ijrefrig.2005.12.002

[4] K.T. Ooi and J. Zhu: Convective heat transfer in a scroll compressor chamber: a 2-D simulation. International Journal of Sciences 43(2004), p.667.

DOI: 10.1016/j.ijthermalsci.2003.11.005

[5] Feng Yi, Eckhard A. Groll and James E, in: Proceedings of International Compressor Engineering Conference at Purdue, USA, C082 (2004).

[6] Feng Yi, Eckhard A. Groll and James E, in: Proceedings of International Compressor Engineering Conference at Purdue, USA, C083 (2004).

[7] Chiachinl L, Yuchoung C and Kuny L: Temperature and thermal deformation analysis on scrolls of scroll compressor. Applied Thermal Engineering 25(2005), p.1724.

DOI: 10.1016/j.applthermaleng.2004.11.008

[8] Qiang Jianguo: Study on basic parameters of scroll fluid machine based on general profile. Mechanism and Machine Theory 45(2010), p.212.

DOI: 10.1016/j.mechmachtheory.2009.08.005

[9] Liu Zhenquan, Wang Jun and Qiang jianguo: Scroll fluid machine and scroll compressor( China Machine Press, Beijing 2009).
