A Fog-Removing Treatment Based on Combining High-Frequency Emphasis Filtering and Histogram Equalization

Abstract:

Fog may cause the impairment of image as well as the decrease in the distinguish ability. The present paper is to get rid of the weather’s influence from the impaired image. According to Retinex theory and exponential relationship between the degradation of the image and the depths of the scene points, it puts forward a fog-removing treatment based on combining high-frequency emphasis filtering and histogram equalization .Firstly, obtain the padding parameters and fill it. Secondly, filter the impaired image using Butterworth highpass filter of order 2. Through the padding parameters, Highpass filtering is not overly sensitive to the value of cutoff frequencies, as long as the radius of the filter is not so small that frequencies near the origin of the transform are passed. In which the gray-level tonality due to the low-frequency components was retained. Lastly, histogram balanced the image gotten last step. The simulation result based on Matlab shows his algorithm can effectively improve the visual effect scene under the condition of mist.

• Periodical: Key Engineering Materials (Volumes 474-476)
• Pages: 2198-2202
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.474-476.2198
• Online since: April 2011
• Authors: Xing Zou, Yu Liu, Ze Fu Tan, Cheng Sheng Tu, Hong Zhang
• Keywords: Butterworth Highpass Filter of Order 2, High-Frequency Emphasis Filtering, Histogram Equalization, Image Fog

References

[1] McCartney. EJ: Optics of Atmosphere: Scattering by Molecules and Particles. New York: John Wiley and Sons (1976), pp.23-32.

[2] Cozman. F, Krotkov. E: Depth from scattering. In: Proceedings of IEEE International Conference on Computer Vision and Pattern Recognition. San Juan, Puerto Rico (1997), pp.801-806.

DOI: 10.1109/cvpr.1997.609419

[3] NS. Kopeika: A system Engineering Approach to imaging. Spie Press (1981).

[4] Narasimhan. SG, Nayar. SK: Vision and atmosphere. International Journal of Computer vision, Vol. 48(3) 2002, pp.233-254.

[5] Narasimhan. SG, Nayar. SK: Contrast restoration of weather degraded images. IEEE Transactions on Pattern Analysis and Machine Intelligence, Vol. 25(6) 2003, pp.713-724.

DOI: 10.1109/tpami.2003.1201821

[6] ZHU. Pei, ZHU. Hong: An Image Clearness Method for Fog. Journal of Image and Graphics, Vol. 19(1) 2004, pp.124-127.

[7] Land. E: An alternative technique for the computation of the designator in the retinex theory of color vision. Proc. Acad. Sci, Vol. 83(10) 1986, pp.3078-3080.

DOI: 10.1073/pnas.83.10.3078

[8] Hurlbert. AC: Formal connections between lightness algorithms. Journal of the Optical Society of America, Vol. 3(10) 1986, pp.1684-1693.

DOI: 10.1364/josaa.3.001684

[9] Richard. E, Rafaek. C, Stenven. L: Digital Image Processing Using MATLAB. Prentice Hall (2004), pp.84-85.
