A Novel Assembly Method for a Micro Direct Methanol Fuel Cell Using Multi-Layer Bonding Technique

Abstract:

A novel assembly method for a micro direct methanol fuel cell (μDMFC) using multi-layer bonding is developed. The anode and cathode plates of the μDMFC are fabricated by using MEMS technologies. PDMS gaskets are introduced to fill the gap between the silicon plate and the membrane electrode assembly (MEA) to prevent fuel or oxidant leaking. To assemble a μDMFC, adhesive tapes and oxygen plasma treatment of the PDMS gasket for surface activation are introduced. In this method, the PDMS gasket with adhesive tapes is bonded to the silicon plate then bonded to the MEA, which fixes the movable components of the μDMFC to simplify the assembly operation. The novel assembly method shows good maneuverability and reliability. The μDMFC shows great performance due to the low internal resistance attributing to this novel assembly method. With thermal insulated holders, the μDMFC generates a power density of 20.29mW/cm². This assembly method is applicable for the assembly of the μDMFC stack.

• Periodical: Key Engineering Materials (Volume 483)
• Pages: 620-625
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.483.620
• Online since: June 2011
• Authors: Yi Ming Zhu, Xiao Hong Wang, Yan An Zhou
• Keywords: Assembly, Micro Fuel Cell, Micro-Electromechanical System (MEMS), Multi-Layer Bonding, μDMFC (Micro Direct Methanol Fuel Cell)

References

[1] E. Sakaue: Micromachining/Nanotechnology in Direct Methanol Fuel Cell, MEMS2005, Miami, pp.600-605.

[2] S. K. Kamarudin, W. R. W. Daud and S. L. Ho: Overview on the Challenges and Developments of Micro-Direct Methanol Fuel Cells (DMFC). Journal of Power Sources Vol. 163 (2007), pp.743-754.

DOI: 10.1016/j.jpowsour.2006.09.081

[3] L. Y. Zhong, X. H. Wang and Y. Q. Jiang: A Silicon-Based Micro Direct Methanol Fuel Cell Stack with Compact Structure and PDMS Packaging, MEMS2007, Kobe, pp.891-894.

DOI: 10.1109/memsys.2007.4433182

[4] Q. Zhang, X. H. Wang and L. Y. Zhong: A Silicon-Based Micro Direct Methanol Fuel Cell with Microblocks in Anode Structure, MEMS2008, Tucson, pp.972-975.

[5] Q. Zhang, X. H. Wang and Y. M. Zhu: Optimized Temperature Control System Integrated into a Micro Direct Methanol Fuel Cell for Extreme Environments. Journal of Power Sources Vol. 192 (2009), pp.494-501.

DOI: 10.1016/j.jpowsour.2009.03.013

[6] Y. A. Zhou, X. H. Wang and X. Lin: An Air-Breathing Silicon-Based Micro Direct Methanol Fuel Cell with A Capillary-Based Water Drawn Out Structure, Transducers2009, Denver, pp.648-651.

DOI: 10.1109/sensor.2009.5285408

[7] K. G. Stanley, Q. M. J. Wu and T. Vanderhoek: Fabrication of a Micromachined Direct Methanol Fuel Cell, IEEE CCECE 2002, pp.450-454.

[8] Y. H. Seo and Y. H. Cho: MEMS-Based Direct Methanol Fuel Cells and Their Stacks Using a Common Electrolyte Sandwiched by Reinforced Microcolumn Electrodes, MEMS2004, Maastricht, pp.65-68.

DOI: 10.1109/mems.2004.1290523

[9] Y. Q. Jiang, X.H. Wang and K.W. Xie: A Micro Direct Methanol Fuel Cell Using PDMS Assembly Technology, Transducers2005, Seoul, pp.303-306.

[10] A. Heinzel and V. M. Barragân: A Review of the State-of-the-art of the Methanol Crossover in Direct Methanol Fuel Cells, Journal of Power Sources Vol. 84 (1999), pp.70-74.

DOI: 10.1016/s0378-7753(99)00302-x
