Designing a Pumping System of Gear Pumps Featuring the Involute Internal Gearing

Abstract:

On the basis of the analysed references it has been shown that an important problem in designing hydraulic machines is to develop a method of designing a pumping system of pumps with the internal gearing, which would integrate designing gears and compenstion elements. The authors of the paper has defined a design algorithm that consists of three basic stages: designing a concept of the system, designing the gear subsystem, and designing the compensation subsystem. The design process at particular stages have been described, and the results have been presented in engineering drawings. An original computer program 'Internal Pumping Set' which enhances the process of designing the pumping system has been created. An application of the program has been presented, and a design of an exemplary pumping system made.

• Periodical: Key Engineering Materials (Volume 490)
• Pages: 64-75
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.490.64
• Online since: September 2011
• Authors: Damian Słodczyk, Jarosław Stryczek
• Keywords: Axial Clearance Compensation, Gear Pump, Gears with Internal Involute Gearing, Pumping System

References

[1] S. Stryczek, Hydrostatic Drive, WNT Warszawa, (1995)

[2] J. Ivantysyn, M. Ivantysyn, Hydrostatiche Pumpen und Motoren. Konstruktion und Berechnung, Vogel, (1993)

[3] C. Dorflinger, E. Reinke, Innenzahnradpumpen: Einstufig auf 345 bar, O+P, number 10/(1997)

[4] R. Pippes, C. Mayer, Gap-compensated high-pressure internal gear pumps, 3rd International Fluid Power Conference, Aachen, (2002)

[5] D. Slodczyk, S. Stryczek, Computer program for the design of hydraulic machines' pumping set with internal involute gearing, 6th International FPNI-PhD Sympsium, Purdue, (2010)

[6] J. Stryczek, Hydraulic Machines' Gears, Wrocław, 2007, http://www.dbc.wroc.pl/dlibra/docmetdata?id=2045&from=&dirids=1

[7] J. Stryczek, Gerotor- und Orbitmachinen, O+P, number 6/(2005)

[8] S. Bednarczyk, J. Stryczek, Axial clearance compensation in the gerotor pump, Proceedings of the 20th International Conference on Hydraulics and Pneumatics, Prague, (2008)

[9] L. Müller, Design of Gear Transmissions, WNT Warszawa, (1996)

[10] S. Bednarczyk, J. Stryczek, Axial clearance compensation in gear displacement machines, Proceedings of the 3rd FPNI-PhD Symposium on Fluid Power, Terrassa, (2004)

[11] K. Ochęduszko, Gears, WNT Warszawa, (2009)

[12] Eckerle pump catalogue, www.eckerle.com, Voith oumo catalogue, www.voithturbo.com.
