Study on the Effect of Rake Angle on Cutting Forces in Ultra-Precision Machining

Abstract:

In recent years, there have been many studies concerning the effect of cutting parameters and tool parameters on the ultra precision machining of electroless nickel. However, there is no known reported study on the relationship between the cutting force and tool rake angle in ultra precision machining of electroless nickel. The objective of this study is to compare and investigate the cutting force with various rake angles for micro machining electroless nickel work pieces by theoretical analysis and experiment. Diamond tools with rake angles of-10^o, 0^o and 10^o were used in the experiment. According to theoretical analysis, the tool with a 10^orake angle induces the smallest cutting force. However, the experiment showed that the tool with zero rake angle always gave us the smallest cutting force for all cutting speeds, cutting depths and pattern pitches.

You might also be interested in these eBooks

Proceedings of Precision Engineering and Nanotechnology

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 516)

Pages:

551-556

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.516.551

Citation:

Cite this paper

Online since:

June 2012

Authors:

Thanh Hung Duong, Kim Huyn Chul, Lee Dong Yoon

Keywords:

Cutting Force, Rake Angle, Single Diamond Tool, Ultra-Precision Machining

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] C.F. Cheung, W. B. Lee, Characterisation of nanosurface generation in single-point diamond turning, Int. J. Mach. Tools Manuf. 41 (2001) 851-875.

DOI: 10.1016/s0890-6955(00)00102-4

Google Scholar

[2] A.Q. Biddut, M. Rahman, K.S. Neo, K.M. Rezaur Rahman, M. Sawa, Y. Maeda, Performance of single crystal diamond tools with different rake angles during mirco-grooving on electroless nickel plated die materials, Int. J. Adv. Manuf. Techn. 33(2007).

DOI: 10.1007/s00170-006-0535-1

Google Scholar

[3] M. Gunay, I. Korkut, E. Aslan, U. Seker, Experimental investigation of the effect of cutting tool rake angle on main cutting force, J. Materials. Proc. Tech. 166 (2005) 44–49.

DOI: 10.1016/j.jmatprotec.2004.07.092

Google Scholar

[4] A. Pramanik, M. Rahman, K.S. Neo, X.P. Li, M. Sawa, Y. Maeda, Ultra-precision turning of electroless-nickel : Effect of phosphorus contents, depth of cut and rake angle, J. Mater. Proc. Tech. 208 (2008) 400-408.

DOI: 10.1016/j.jmatprotec.2008.01.006

Google Scholar

[5] W.R. DeVries, Analysis of Material Removal Processes, first ed., Springer-Verlag, New York, (1992).

Google Scholar
