Micro-Ball Endmilling of Tungsten Carbide for Micro-Molding and Prototyping Applications

Abstract:

This paper presents micro-ball end milling of tungsten carbide using a CBN cutter to investigate its capability for machining slots for micro-moulds. Crack-free slots were machined at different axial depths of cut by inclining the work piece surface at different angles to the spindle axes to study the influence of these machining parameters on the cutting mechanism and surface finish. The experimental results show that up to 150 µm deep slots can be finished efficiently on tungsten carbide work pieces without leaving any fracture marks. It was identified that the chip disposal ability of micro-ball end milling reduced with increase in axial depth of cut. The cutting action was more efficient in up milling cuts compared to that in down milling when machining a slot. The inclination of the work piece proved propitious for machining slots with high-quality finish on tungsten carbide work pieces and a larger inclination angle also facilitated chip disposal.

You might also be interested in these eBooks

Proceedings of Precision Engineering and Nanotechnology

View Preview

Info:

Periodical:

Key Engineering Materials (Volume 516)

Pages:

591-594

DOI:

https://doi.org/10.4028/www.scientific.net/KEM.516.591

Citation:

Cite this paper

Online since:

June 2012

Authors:

Muhammad Arif, Mustafizur Rahman, Yoke San Wong, Kui Liu

Keywords:

Ductile-Mode Milling, Micro Ball End Milling, Micro Cutting, Tungsten Carbide

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] M.B. Cai, X.P. Li, M. Rahman, Study of the mechanism of nanoscale ductile mode cutting of silicon using molecular dynamic simulation, Int. J. Mach. Tools. Manuf. 47 (2007) 75-80.

DOI: 10.1016/j.ijmachtools.2006.02.016

Google Scholar

[2] W.S. Blackley, R.O. Scattergood, Ductile regime model for diamond turning of brittle materials. Precis. Eng. 13(1991) 95-102.

DOI: 10.1016/0141-6359(91)90500-i

Google Scholar

[3] S. Arefin, X.P. Li, M. Rahman, K. Liu, The upper bound of tool edge radius for nanoscale ductile mode cutting of silicon wafer, Int. J. Adv. Manuf. Technol. 31(2007) 655-662.

DOI: 10.1007/s00170-005-0245-0

Google Scholar

[4] F.Z. Fang, L.J. Chen, Ultra-precision cutting for ZKN7 glass. Ann. ClRP 49(2000) 17-20.

DOI: 10.1016/s0007-8506(07)62887-x

Google Scholar

[5] K. Liu, X.P. Li, S.Y. Liang, Nanometer-scale ductile cutting of tungsten carbide, J. Manuf. Process. 6 (2004) 187-195.

Google Scholar

[6] K. Liu, X.P. Li, Modeling of ductile cutting of tungsten carbide, Trans. NAMRI SME 29 (2001) 251-258.

Google Scholar

[7] M. Arif, M. Rahman, Y.S. Wong, Analytical modeling of ductile-regime machining of tungsten carbide by endmilling, Int. J. Adv. Manuf. Technol. 55 (2011) 53-64.

DOI: 10.1007/s00170-010-3027-2

Google Scholar
