Development of a High-Speed Nanoprofiler Using Normal Vector Tracing

Abstract:

A new high-speed nanoprofiler was developed in this study. This profiler measures normal vectors and their coordinates on the surface of a specimen. Each normal vector is determined by making the incident light path and the reflected light path coincident using five-axis simultaneously controlled stages. From the acquired normal vectors and their coordinates, the three-dimensional shape is calculated by a reconstruction algorithm. In this study, a concave spherical mirror with a 400 mm radius of curvature was measured. As a result, a peak of 30 nm PV was observed at the centre of the mirror. Measurement repeatability was 1 nm. In addition, cross-comparison with a Fizeau interferometer was implemented and the results were consistent within 10 nm. In particular, the high spatial frequency profile was highly consistent, and any differences were considered to be caused by systematic errors.
