The Project of Tank Inspection Robot

Abstract:

The paper presents the project of tank inspection robot. In order to discuss the designing process, algorithm of design has been provided. There are four design stages: the analysis of the construction problem, the synthesis, testing/improving robots construction and finally testing it. First stage of project process is divided into constructive and imitative analysis. Constructive analysis means searching for still not existing solutions of robots and detection methods. In this paper we concentrate only on constructive analysis.

• Periodical: Key Engineering Materials (Volume 518)
• Pages: 375-383
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.518.375
• Online since: July 2012
• Authors: Mariusz Giergiel, Tomasz Buratowski, Piotr Małka, Krzysztof Kurc, Piotr Kohut, Konrad Majkut
• Keywords: Inspection Robot, Mobile Robot, Robot for Diagnostics of Tanks, Robot for Tanks Inspection, Underwater Robot

References

[1] Schempf H., Chemel B., Everett N., Neptune: above-ground storage tank inspection robot system. IEEE Robotics Autom. Mag. 22, 1995, p.9–15.

DOI: 10.1109/100.392414

[2] Hartsell D. R., Putting the maverick fuel-tank inspection robot to the test, IEEE Robot. Autom. Mag., vol. 6, no. 3, Feb. 1999, p.54–64.

[3] Sogi T., Kawaguchi Y., Morisaki H., Ohkawa K., Kai N., Hayakawa H.: Inspection Robot for Spherical Storage Tanks, 26th Annual Conference of the IEEE Industrial Electronics Society, Volume 1, 22-28 Oct. 2000, p.393 – 398.

DOI: 10.1109/iecon.2000.973182

[4] Yoshifumi K.: Development of an Inspection Robot for Spherical Storage Tanks; Journal of the Robotics Society of Japan; vol: 21, 2003, pp.770-775.

[5] Marsh C. P., Siddique A., Temple B., Hock V. M., Robb F.: Fury: Robotic in-situ inspection/condition assessment system for underground storage tanks, US Army Corps of Engineers, Washington, Tech. Rep., (2005).

[6] La Rosa G., Messina M., Muscato G., Sinatra R.: A low-cost lightweight climbing robot for the inspection of vertical surfaces, Mechatronics, Volume 12, Issue 1, Feb. 2002, pp.71-96.

DOI: 10.1016/s0957-4158(00)00046-5

[7] Pack R. T., Christopher J. L. Jr., Kawamura K.: A Rubbertuator-based structure-climbing inspection robot, Proceedings of the 1997 IEEE International Conference on Robotics and Automation, Volume 4, (1997).

DOI: 10.1109/robot.1997.619060

[8] Schempf H.: Houdini: Locomotion analysis-driven design of an in-tank mobile cleanup robot, Proceedings of the Transactions of the American Nuclear Society volume 73, 1995, pp.466-468.

[9] Burdziński Z.: Teoria ruchu pojazdu gąsienicowego, Wydawnictwa Komunikacji i Łączności, Warszawa (1972).

[10] Chodkowski A. W.: Konstrukcja i obliczanie szybkobieżnych pojazdów gąsienicowych, Wydawnictwa Komunikacji i Łączności, Warszawa (1990).

[11] Chodkowski A. W.: Badania modelowe pojazdów gąsienicowych i kołowych, Wydawnictwa Komunikacji i Łączności, Warszawa (1982).
