Micro-Aspheric Mold Polishing Utilizing Magnetostrictive Vibration-Assisted Polishing Machine

Abstract:

Micro-aspheric lenses molded by micro-aspheric ceramic molds are increasing in the optical systems such as digital cameras and blu-ray players. To finish the molds with high accuracy and low surface roughness, in this paper, the micro-aspheric mold made of Electroless nickel plating are polished by using the newly developed 5-axis magnetostrictive vibration-assisted polishing machine. The magnetostrictive vibrating polisher generates a lateral vibration at 9.2 kHz with amplitude of 30 μm. The polishing pressure is controlled by a balance adjustment mechanism and the polishing load is controllable within a range of 2 mN ~ 20 mN with a resolution of 2 mN. The motion resolution of the X-Y-Z table is 0.1 μm in each direction. The C-axis rotary table is mounted on a B-axis tilting table and the workpiece is mounted on the C-axis rotary table with a vacuum chuck. According to the polishing experiments, the form accuracy was improved to 200 nm P-V and the surface roughness was reduced to 10 nm Rz (1 nm Ra).

• Periodical: Key Engineering Materials (Volumes 523-524)
• Pages: 768-773
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.523-524.768
• Online since: November 2012
• Authors: Jiang Guo, Hirofumi Suzuki, Shinya MORITA, Yutaka Yamagata, Toshiro Higuchi
• Keywords: Die, Mold, Polishing, Vibration
